Axxius 800 User Manual

Axxius 800 - Release 2.2 5-83
CLI Commands
set
set (ds3)
Use the set (ds3) command to set up DS3 interfaces. The command specifies a range of
interfaces and the setting to apply.
Syntax: set {ds3-addr} {setting}
Example: set a:1 framing m23
To set DS3 1 (port 1) on a DS3 Controller (slot A) to use M23 framing.
{ds3-addr}
DS3 address in the form {slot:port}.
{setting}
slot A for the controller card, or 1-8 for service cards.
port Port number, range or all.
down Set the DS3 as Out-of-Service
up Set the DS3 as In-Service. Enables alarm reporting (and LED) for the
port specified
berthreshold Set Bit Error Rate protection switchover threshold.
{value} 4-8 for 10e-4 to 10e-8
clock Set the transmit clock source
loop Set to clock recovered from the DS3 receive
normal Set to master transmit clock source
dejitter Turn the De-jitter buffer on or off
off De-jitter buffer off
on De-jitter buffer on
equipment Set equipment loopback on the DS3 or PMDL (Path Maintenance Data
Link) ID
id Set the DS3 equipment PMDL ID string
Command syntax: set {ds3-addr} equipment id
{"string"}
{"string"} = transmission vendor’s identification, up to
30 characters, enclosed in quotes.
loopdown Disable equipment loopback on the DS3
loopup Enable equipment loopback on the DS3
facility id Set the DS3 facility PMDL ID string
Command syntax: set {ds3-addr} facility id {"string"}
{"string"} = transmission vendor’s identification, up to 38 characters,
enclosed in quotes.
