CLI Commands
set
set (ds1)
Use the set (ds1) command to set up DS1 interfaces. The command specifies a range of
interfaces and the setting to apply.
Syntax: set {ds1-addr} {setting}
Example: set a:1 framing esf
To set DS1 1 (port 1) on a DS1 Controller to use ESF framing.
{ds1-addr}
The Controller DS1 addresses are different on the DS3 and DS1 Controller, however the
DS1 address on the services cards does not change with Controller type (DS3 or DS1). \
{setting}
DS1 Address on a DS3 Controller in the form {slot:port:channel}
slot A for the DS3 Controller card.
port Port number, range or all.
ds1 channel Channel number, range or all.
DS1 Address on a DS1 Controller or service cards (with DS1 or DS3 controller) in
the form {slot:port}
slot A for the DS1 Controller card, or 1-8 for service cards.
port Port number, range or all.
ais Enable/Disable AIS Forwarding on the DS1. Default is Disabled
down Set the DS1 as Out-of-Service
equipment Set equipment loopback on the DS1
loopdown Disable equipment loopback on the DS1
loopup Enable equipment loopback on the DS1
fdl Set the Facilities Data Link (FDL) capabilities
none Disable FDL output messages
t1403 Enable T1.403 FDL performance messages
framing Set the DS1 framing type to one of the following:
d4 To D4 Superframe (SF) framing
esf To Extended Superframe (ESF) framing
