Axxius 800 User Manual

5-60 Axxius 800 - Release 2.2
CLI Commands
load
load
WARNING! BEFORE LOADING A DOWN-LEVEL OF ROUTER CODE TO AN
A
DIT, SAVE THE CONFIGURATION TO A FILE. CONFIGURATION MAY BE RESET TO
THE DEFAULT SETTING AND CURRENT CONFIGURATION LOST.
load tftp
The load tftp command will download software via TFTP to the Controller or to the TSR card.
Note: A TFTP server must be running on the host system for this command to be successful.
Syntax: load {ctrlr-id|number} tftp {ip-addr} {"file-name"}
Example: load a1 tftp 192.102.3.168 "axxius1_0_all.mgm"
The example will download the Controller software file "axxius1_0_all.mgm"
to the Controller in slot 1, via TFTP.
Example: load 5 tftp 172.26.100.25 "tsr1_20.mgm"
The example will download the Router software file "tsr1_20.mgm" to a TSR
card in slot 5 via TFTP.
Example: load 5 tftp 172.26.100.25 "config.txt"
The load tftp command is modified to add special processing when a filename
ends with "txt". In this case, the .txt file is handled as an ASCII file containing
CLI commands to configure the Axxius 800.
{ctrlr_id|number}
{ip-addr}
The host IP address in the form of xxx.xxx.xxx.xxx, where xxx is a number from 0-255. If
not supplied the host IP address from the database will be used.
{"file-name"}
The software file to load including path. Must be enclosed with quotes.
The file-type of the downloading files must be .mgm, or .txt.
ctrlr_id Controller identifier to download the software to.
A1, A2 All, Active or Standby. Note: always load to the standby
controller, in a redundant system, reset and switch controllers,
then load again to the new standby controller.
rtr_card-addr Slot number (1-8) of a Router card to load the software file to.
