Axxius 800 User Manual

5-40 Axxius 800 - Release 2.2
CLI Commands
connect
connect
Use the connect command to create two-way connections between any DS0 channels of the
service or controller cards.
Syntax: connect {slot:port|slot:port:channel}
{slot:port|slot:port:channel}
Use the disconnect command to delete connections.
Example: connect A:2:1-24 3:1
Connects all 24 channels on port address #2 (DS1) on the controller card
(slot A) to port address #1 V.35 in slot 3.
{slot:port|slot:port:channel}
Channel Associated Signaling (CAS) Conversions
Cross-connects are done at a DS0 level. The following rules need to be kept in mind while
performing cross-connects for the voice cards.
slot A for the controller card, or 1-8 for service cards.
port Port number or range.
channel Channel number or range, for T1 ports.
DS0
FXO Analog
LS GS DPT LSCPD DPT = Dial Pulse Termination
T1 DS0 EMDW = E&M Delayed Wink start
LS Y N N Y EMI = E&M Immediate start
GS N Y N N EMICPD = E&M Immediate Start with Calling
Party Disconnect
EMDW N N N N EMW = E&M Wink start
EMI N N Y N GS = Ground Start
EMICPD N N N N LS = Loop Start
EMW N N N N LSCPD = Loop Start Calling Party Disconnect
