Axxius 800 - Release 2.2 5-39
CLI Commands
clear
clear (router) performance
Use the clear (router) performance command to clear the runtime statistics that are displayed
by the status (router) performance command. This command takes effect immediately.
Syntax: clear {rtr_card-addr} performance {all|lan|wan}
Example: clear 4 performance all
The example will clear all of the runtime statistics on the router card in slot 4.
{rtr_card-addr}
The slot number (1-8) that contains the Router card.
{all|lan|wan}
all Clear both LAN and WAN statistics
lan Clear the LAN statistics only.
wan Clear the WAN statistics only.
