A-72
Carlon
®
Blue
™
PVC Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
SN-236-FS
SN-241
SN-241-FS
N2-1614-MNC
SN-236
N2-1614-RNC SN-236-V
B232A-UPC
SB2-236-FS
B232B-UPC
Two-Gang Nail-On — For New Work
Two-Gang Bracket — For New Work
B234ADJ
Two-Gang Adjustable — For New Work
• Design enables adjustment from 0" to 1
3
⁄4" after installation
• Ideal for new work or retrofit upgrade applications
• Backless low-voltage bracket and floor box designs available
• Ideal for various drywall thicknesses and wall finishes
Two-Gang Adjustable 34.0 Cu. In.
CAT. NO.
SIZE
CU. IN.
MOUNTING
MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
B234ADJ 34.0 Adjustable
Bracket
Adjusts 0"–1
3
⁄4" 4 W x 3
5
⁄8 H x 3 D 16
B234ADJC 34.0 Adjustable
Bracket
Large 220V Knockout 5
5
⁄8 W x 3
5
⁄8 H x 3 D 16
Two-Gang Nail-On 32.0–41.0 Cu. In.
CAT. NO.
SIZE
CU. IN. MOUNTING MEANS DESCRIPTION DIMENSIONS (IN.) STD. CTN.
B232A-UPC 32.0 Captive Nails — 3
3
⁄4 L x 4 W x 3 D 50
N2-1614-MNC 32.0 Angled Side Nails
7
⁄32" Offset Wallboard Tabs Cable-Lok
™
Clamps Bulk Packed 4
1
⁄16 L x 3
5
⁄8 W x 2
3
⁄4 D 50
N2-1614-RNC 32.0 Angled Side Nails No Wallboard Tabs Cable-Lok
™
Clamps Bulk Packed 4
1
⁄16 L x 3
5
⁄8 W x 2
3
⁄4 D 50
SN-236 36.0 Compound Angled Nails
3
⁄8" Offset Wallboard Tabs Molded Fast Clamp 4 L x 3
5
⁄8 W x 3
1
⁄8 D 50
SN-236-FS 36.0 Compound Angled Nails
3
⁄8" Offset Wallboard Tabs Molded Fast Clamp/Fast Set 4 L x 3
5
⁄8 W x 3
1
⁄8 D 50
SN-236-V 36.0 Compound Angled Nails
3
⁄8" Offset Wallboard Tabs Molded V-Clamp 4 L x 3
5
⁄8 W x 3
1
⁄8 D 50
SN-241 41.0 Compound Angled Nails
3
⁄8" Offset Wallboard Tabs Molded Fast Clamp 4 L x 3
5
⁄8 W x 3
5
⁄8 D 50
SN-241-FS 41.0 Compound Angled Nails
3
⁄8" Offset Wallboard Tabs Molded Fast Clamp/Fast Set 4 L x 3
5
⁄8 W x 3
5
⁄8 D 50
Two-Gang Bracket 32.0–36.0 Cu. In.
CAT. NO.
SIZE
CU. IN. MOUNTING MEANS DESCRIPTION
DIMENSIONS
(IN.)
STD.
CTN.
B232B-UPC 32.0 Bracket for
3
⁄8" to
5
⁄8"
Wallboard — Steel or
Wood Stud Mounting
— 3
3
⁄4 L x 4 W
x 3 D
50
SB2-236-FS 36.0 Two
3
⁄8" Offset
Wallboard Tabs; Molded
Fast Clamps/Fast Set
3
⁄8" Offset 3
9
⁄16 L x 4 W
x 3
9
⁄16 D
20
