Low-Voltage Structured Cable Management System
Boxes & Covers — Carlon
®
Non-Metallic Boxes
SC34CC SC12CC SC14CC
Cable Clips
Pre-installed nails provide fast and easy installation for either
a single cable, two to three cables or one bundled cable.
Conduit Clamps
Designed to secure Resi-Gard
®
raceway or bundled cable.
CAt. No. Size (iN.) StANdArd BAg QuANtity Std. CtN.
SC14CC
1
⁄4 1 Ea. (Equals One Bag of 100 Clips) 10 Bags of 100
SC12CC
1
⁄2 1 Ea. (Equals One Bag of 25 Clips) 310 Bags of 25
SC34CC
3
⁄4 1 Ea. (Equals One Bag of 10 Clips) 20 Bags of 10
CAt. No. Size (iN.) StANdArd BAg QuANtity Std. CtN.
SCe977eC
3
⁄4 1 Ea. (Equals One Bag of Five Clamps) 20 Bags of 5
SCe977FC 1 1 Ea. (Equals One Bag of Five Clamps) 12 Bags of 5
SCe977gC 1
1
⁄4 1 Ea. (Equals One Bag of Five Clamps) 8 Bags of 5
SCe977HC 1
1
⁄2 1 Ea. (Equals One Bag of Five Clamps) 6 Bags of 5
SCe977JC 2 1 Ea. (Equals One Bag of Five Clamps) 6 Bags of 5
Note: Each clamp requires two screws, two nuts and/or two bolts.
Cutters
Ideal for fast, smooth field cuts for up to 1" diameter Resi-Gard
®
non-metallic flexible raceway.
The large PVC Cutter is ideal for cuts up to 2" diameter non-metallic rigid and flexible raceway.
reCommeNded pipe
AppliCAtioN ANd SizeS
Set-up time
(evAporAtioN rAte)
reCommeNded
iNStAllAtioN temp.
lAp SHeAr
@ 73˚ F
viSCoSity At 75˚ F
AS mANuFACtured
For use with Resi-Gard
®
, Riser-Gard
®
,
P&C Flex
™
and Carlon PVC fittings.
Up through 6" diameter.
10°–30° F Use extra caution 40°–100° F 2 hrs. 350 psi 500–900 cps
30°–50° F 5–6 minutes 16 hrs. 800 psi
50°–70° F 3–4 minutes 72 hrs. 1500 psi
70°–90° F 1–2 minutes
Resi-Gard
®
Solvent Cement
CAt. No. Size (iN.) AppliCAtor deSCriptioN
Std.
CtN.
vC9963SC Pint Brush Resi-Gard
®
Solvent Cement Clear 24
Meets ASTM D-2564.
CAt. No. Size (iN.) Std. CtN.
CC120B 8 10
CAt. No. Size (iN.) Std. CtN.
CC125 9 1
CAt. No. Size (iN.) Std. CtN.
CC122 17
1
⁄2 1
Small Cutter
For fast, smooth field cuts of
1
⁄2"
through 1" innerduct.
Large Cutter
For clean cuts of
conduit
1
⁄2" through 2".
Medium Cutter
For fast square,
smooth, field cuts on
conduit
1
⁄2" through 1
1
⁄4".
