Low-Voltage Structured Cable Management System
Boxes & Covers — Carlon
®
Non-Metallic Boxes
Quick-Connect Coupling
Resi-Gard
®
Fittings
Male Terminal Adapter*
Quick-Connect Threaded Adapter Standard Couplings*
Quick-Connect Snap-In-Adapter
PVC Lock Nut
CAT. NO. SIZE (IN.)
STD.
CTN.
LT9E•
3
⁄4 700
LT9F• 1 600
• UL Recognized.
CAT. NO. SIZE (IN.)
STD.
CTN.
SCE940G• 1
1
⁄4 30
SCE940H• 1
1
⁄2 25
SCE940J• 2 30
• UL Listed E23018.
* Must be cemented to Resi-Gard
®
Flexible Raceway using ONLY Resi-Gard
®
Solvent Cement.
CAT. NO.
SIZE (IN.) STD.
CTN.
SCE943G• 1
1
⁄4 50
SCE943H• 1
1
⁄2 25
SCE943J• 2 50
• UL Listed E23018.
* Must be cemented to Resi-Gard
®
Flexible Raceway using ONLY Resi-Gard
®
Solvent Cement.
CAT. NO. SIZE (IN.)
STD.
CTN.
SCA253E•
3
⁄4 25
SCA253F• 1 20
• UL Listed E86720
CAT. NO. SIZE (IN.)
STD.
CTN.
SCA243E•
3
⁄4 25
SCA243F• 1 20
• UL Listed E86720
CAT. NO. SIZE (IN.)
STD.
CTN.
SCA240E•
3
⁄4 25
SCA240F• 1 20
• UL Listed E86720
