Low-Voltage Structured Cable Management System
Boxes & Covers — Carlon
®
Non-Metallic Boxes
Standard-Length Coils
CAT. NO. SIZE (IN.) PULL TAPE DESCRIPTION REEL LENGTH (FT.)
SCE4X1-100•
3
⁄4 Empty* Flexible Raceway 100
SCF4X1C-100• 1 900 lbs. Flexible Raceway 100
SCG4X1C-100• 1
1
⁄4 900 lbs. Flexible Raceway 100
SCH4X1C-50• 1
1
⁄2 900 lbs. Flexible Raceway 50
SCJ4X1C-100• 2 900 lbs. Flexible Raceway 50
• UL Listed E151168.
FT-1 Rated
* If installing own tape, a lubricated polyester is recommended.
Ideal for providing a main chase from the main distribution panel to a
secondary hub in the attic or basement, Resi-Gard
®
non-metallic flexible
raceway is available in
3
⁄4" to 2" diameter sizes with factory-installed pull
tape in sizes 1" to 2". The raceway is hand bendable, lightweight and
easily cut to length to reduce scrap. Bright orange color clearly signifies
a low-voltage installation.
Resi-Gard
®
Flexible Raceway
Standard-Length Reels*
CAT. NO. SIZE (IN.) PULL TAPE DESCRIPTION REEL LENGTH (FT.)
SCE4X1-1000•
3
⁄4 Empty Flexible Raceway 1000
SCF4X1C-1500• 1 900 lbs. Flexible Raceway 1500
SCJ4X1C-500• 2 900 lbs. Flexible Raceway 500
* Made to order
• UL Listed E151168.
