PVC Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
One-Gang Nail-On — For New Work
RN-23 RN-23-FS
B122A-UPC
RD-30
MB-18-FSMB-18
B108B-UPC B118B-UPC
One-Gang Brackets — For New Work
One-Gang Nail-On 22.0–22.5 Cu. In.
CAT. NO.
SIZE
CU. IN.
MOUNTING
MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
B122A-UPC 22.0 Captive Nails — 3
3
⁄4 L x 2
1
⁄4 W x 3
1
⁄2 D 100
RN-23 22.5 Recessed
Angled Nails
— 3
21
⁄32 L x 2
5
⁄16 W x 3
3
⁄8 D 100
RN-23-FS 22.5 Recessed
Angled Nails
Fast-Set 3
21
⁄32 L x 2
5
⁄16 W x 3
3
⁄8 D 100
One-Gang Nail-On 30.0 Cu. In.
CAT. NO.
SIZE
CU. IN.
MOUNTING
MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
RD-30 30.0 Recessed
Angled Nails
Large KO for #6
or #8 Cable
3
11
⁄16 L x 2
5
⁄16 opening 3
7
⁄8
overall W x 3
5
⁄8 D
50
One-Gang Brackets 8.0–18.0 Cu. In.
CAT. NO.
SIZE
CU. IN. MOUNTING MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
B108B-UPC 8.0 Bracket — 3
5
⁄8 L x 2
3
⁄8 W
x 1
1
⁄4 D
25
B118B-UPC 18.0 Bracket for
3
⁄8" to
5
⁄8"
Wallboard –
Steel and Wood
Stud Mounting
— 3
3
⁄4 L x 2
1
⁄4 W
x 2
15
⁄16 D
5
MB-18 • 18.0 Molded Side Bracket
for Wood/Steel Studs
1
⁄2" Depth Gage
Lever Clamps
3
21
⁄32 L x 2
5
⁄16 W
x 2
15
⁄16 D
100
MB-18-FS • 18.0 Molded Side Bracket
for Wood/Steel Studs
Fast-Set 3
21
⁄32 L x 2
5
⁄16 W
x 2
15
⁄16 D
100
• Manufactured housing — MB-18 and MB-18-FS.
