A-112
Low-Voltage Structured Cable Management System
Boxes & Covers — Carlon
®
Non-Metallic Boxes
CAt. No.
Size
Cu. iN.
MouNtiNg
MeANS DeSCriptioN DiMeNSioNS (iN.)
StD.
CtN.
SC100ADJC• 21 Adjustable
Bracket
1-Gang 3.56 L x 3.88 W x 1.69 D 24
SC200ADJC• 34 Adjustable
Bracket
2-Gang 3.56 L x 5.63 W x 1.69 D 20
• UL Listed E216492.
CAt. No.
Size
Cu. iN.
MouNtiNg
MeANS DeSCriptioN DiMeNSioNS (iN.)
StD.
CtN.
SC100SC• N/A Tape 1-Gang 3.68 L x 2.36 W x 3.10 D 24
• UL Listed E216492.
SC100ADJC
SC100SC
Low-Voltage Add-On Bracket
• Dual-voltagecapabilityaccommodateshigh-
andlow-voltagedevicesinthesamebox
• Attachestovirtuallyanynon-metallicelectrical
boxaslongasthere’sasideforthetapeto
stickto
• Acceptsatwo-gangfaceplate
•
3
⁄4"Resi-Rings
®
• Enablestheinstallationofmostrectangular
yokeplates
Low-Voltage Adjustable Brackets
• Accommodatesvaryingfinished-wallthicknesses—
idealforwoodpaneling,tileorstuccowalls
• Withtheturnofascrew,adjusttoanywallthickness
• Steelmountingbracketprovidesasecuremount
• Backlessdesignaccommodateslarge/deep
low-voltagedevices
• Eliminatescuttingthebacksoffelectricalboxes
• Accommodatesbend-radiusrequirementsfor
low-voltagecabling
• Providesamplespaceforinstallation
• Removablebracketandinterchangeablemountingbracket
—upgradefromaone-gangtoatwo-ganganytime
