Low-Voltage Structured Cable Management System
Boxes & Covers — Carlon
®
Non-Metallic Boxes
Our complete line of quick-connect couplings, adapters, cable clips, conduit clamps and solvent cement make
for quick, easy professional installation of Resi-Gard
®
Flexible Raceway.
What could be easier than converting one of our Carlon
®
SuperBlue
®
boxes for both high- and low-voltage
use? Just slip the divider into place and you’re ready to go. Great for situations requiring a dual-voltage
fire-rated box.
Resi-Gard
®
Flexible Raceway
and Fittings
Available in five sizes from
3
⁄4" to
2", with factory-installed pull tape
in sizes 1" to 2", our Resi-Gard
®
Flexible Raceway provides a main
chase from the main distribution
panel to a secondary hub in the
attic or basement. Ideal for easy access to add cable
or service upgrades or leave empty for future expansion.
Recessed Dual-Voltage
3-Gang Old Work Plate
The New Carlon
®
RDV 3-Gang
Old Work Plate has been
developed to simplify today’s
in-home entertainment/networking
needs. The box is designed to
accommodate the wires, cables
and cords used with flat-panel display installations.
It features a two-gang low-voltage opening and a one-
gang opening for an outlet/switch box (boxes, devices
and plates not included)… SC300PRB and SC300PRR
The high-gloss, recessed design eliminates unsightly wires, cables and cords and blends with any décor.
The RDV Old Work Plate makes installing flat panel displays faster and easier!
Drop-In Floor Box
The Carlon
®
Drop-In Floor Box
with Brass Cover combines
many of the same features of
our existing floor box line with
the strength, durability and style
necessary to accommodate
today’s residential electrical/
telecommunication needs. The Carlon
®
Drop-In Floor
Box is the
fastest, easiest way for contractors to put
a floor socket anywhere they need it! It’s designed
to accommodate line voltage and low-voltage
applications… E971FBDI-2 and E971FBDIB-2
Turn off electricity before starting. Drill hole in floor using hole saw. Pull romex through floor. Connect
receptacle wires to romex. Brass cover snaps into place. Use a small screwdriver to pry open brass cover
to plug in appliance.
For more information about this floor box, refer to www.tnb.com or the Thomas & Betts Residential catalog.
5
Dual-Voltage Box/Bracket
For applications where a combined
high- and low-voltage closed-back
box is needed, such as placement
in a fire-rated wall, we offer our
Carlon
®
SuperBlue
®
two-, three-
and four-gang wiring boxes with
a slip-in-place divider to give
you the split box you need for the low-voltage
outlet… SCDIV
