Phenolic Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
AO Round Conduit Boxes and Covers
Weatherproof Device Boxes and Covers
A04-12
A04-34 A0-51
FSC-12
FSC-51
FSC-54
FSC-34
FSC-53
FSC-55
CAt. No.
size
Cu. iN. MouNtiNg MeANs DesCriptioN
DiMeNsioNs
(iN.)
stD.
CtN.
AO4-12 • 12.0 Four
1
⁄2" Threaded KOs Round Box 4
1
⁄8 Dia. x 1
7
⁄8 D 10
AO4-34 • 12.0 Four
3
⁄4" Threaded KOs Round Box 4
1
⁄8 Dia. x 1
7
⁄8 D 10
AO-51 • — Stainless Steel Screws Black Cover
with Gaskets
— 10
• Not UL Listed.
CAt. No.
size
Cu. iN.
MouNtiNg
MeANs DesCriptioN DiMeNsioNs (iN.)
stD.
CtN.
FsC-12 16.0 One
1
⁄2" Threaded
KO in Each End
Device Box 4
7
⁄16 L x 1
25
⁄32 W x
2
9
⁄16 D
10
FsC-34 16.0 One
3
⁄4" Threaded
KO in Each End
Device Box 4
7
⁄16 L x 1
25
⁄32 W x
2
9
⁄16 D
10
FSC-51 • — Stainless
Steel Screws
Blank Cover
with Gaskets
— 10
FSC-53 • — Stainless
Steel Screws
Duplex
Receptacle
Cover with
Gasket
— 10
FSC-54 • — Stainless
Steel Screws,
1.409" Dia.
Single
Receptacle
Cover with
Gasket
— 10
FSC-55 • — Stainless
Steel Screws
Switch Cover
with Gasket
— 10
• Not UL Listed.
