A-103
Phenolic Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
5060 Brown
5060 whIte
5070 Ivory
5070 Brown
5060 Ivory
5070 whIte
One-Gang
Two-Gang
6
1
⁄2" Outside Diameter
5072 Brown
5072 whIte5072 Ivory
5080 whIte
5080 Ivory
9.8–14.0 Cu. In.
CAT. NO.
SIZE
CU. IN. MOUNTING MEANS DIMENSIONS (IN.)
STD.
CTN.
5060 Brown • 9.8 Screws 4
1
⁄2 L x 2
3
⁄4 W x 1
1
⁄8 D 100
5060 IVORY 9.8 Screws 4
1
⁄2 L x 2
3
⁄4 W x 1
1
⁄8 D 100
5060 WHITE 9.8 Screws 4
1
⁄2 L x 2
3
⁄4 W x 1
1
⁄8 D 100
5070 Brown • 14.0 Screws 4
1
⁄2 L x 2
3
⁄4 W x 1
1
⁄8 D 100
5070 IVORY 14.0 Screws 4
1
⁄2 L x 2
3
⁄4 W x 1
1
⁄8 D 100
5070 WHITE 14.0 Screws 4
1
⁄2 L x 2
3
⁄4 W x 1
1
⁄8 D 100
• Note: Only the “Brown” is Phenolic — the White and Ivory are a urea material.
23.8 Cu. In.
CAT. NO.
SIZE
CU. IN. MOUNTING MEANS DIMENSIONS (IN.)
STD.
CTN.
5072 Brown • 23.8 Screws 4
9
⁄16 L x 4
1
⁄2 W x 1
5
⁄8 D 50
5072 IVORY 23.8 Screws 4
9
⁄16 L x 4
1
⁄2 W x 1
5
⁄8 D 50
5072 WHITE 23.8 Screws 4
9
⁄16 L x 4
1
⁄2 W x 1
5
⁄8 D 50
• Note: Only the “Brown” is Phenolic — the White and Ivory are a urea material.
3.8 Cu. In.
CAT. NO.
SIZE
CU. IN. MOUNTING MEANS DIMENSIONS (IN.)
STD.
CTN.
5080 Brown • 3.8 Screws, Box O.D. 6
1
⁄4 L x 3
1
⁄8 W x
3
⁄4 D 50
5080 IVORY 3.8 Screws, Box O.D. 6
1
⁄4 L x 3
1
⁄8 W x
3
⁄4 D 50
5080 WHITE 3.8 Screws, Box O.D. 6
1
⁄4 L x 3
1
⁄8 W x
3
⁄4 D 50
• Note: Only the “Brown” is Phenolic — the White and Ivory are a urea material.
5080 Brown
