Phenolic Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
3
1
⁄ 2 " Brackets 14.0–20.5 Cu. In.
CAT. NO. SIZE CU. IN. MOUNTING MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
3080
†
14.0 Ears High Clamps 3
1
⁄2 Dia. x 2
1
⁄8 D 50
3080-9 • 14.0 #9 Snap-In Bracket High Clamps 3
1
⁄2 Dia . x 2
1
⁄8 D 50
3080-902 • 14.0 #9 Snap-In Bracket #36 Clamps Bulk Packed 3
1
⁄2 Dia. x 2
1
⁄8 D 50
3080-9-40 • 14.0 #9 Snap-In Bracket High Clamps & #40 Ground Strap 3
1
⁄2 Dia. x 2
1
⁄8 D 50
3080-9-PC • 14.0 #9 Snap-In Bracket Non-Metallic Clamps 3
1
⁄2 Dia. x 2
1
⁄8 D 50
3080-9-SQ 14.0 #9 Snap-In Bracket High Clamps 3
1
⁄2 Dia. x 2
1
⁄8 D 50
3080-SQ 14.0 Ears High Clamps 3
1
⁄2 Dia. x 2
1
⁄8 D 50
3000-9-PC 20.5 #9 Snap-In Bracket Non-Metallic Clamps 3
1
⁄2 Dia. x 2
1
⁄8 D 50
3000-9-UB • 20.5 #9 Snap-In Bracket High Clamps 3
1
⁄2 Dia. x 2
1
⁄8 D 50
• Listed for fixture support up to 15 lb. in walls only.
†
Listed for fixture support up to 50 lbs.
3080-9-PC
3080-9
3080
3080-902
3000-9-UB
3080-9-40
3080-9-SQ 3080-SQ
4062 Ivory, 4062 Brown, 4062 whIte
4052 whIte 4061
Plaster Rings and Covers for 4" Outlet Boxes
CAT. NO. SIZE CU. IN. DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
3051 — Round Flat Blank, Fits #3000, #3020 & #3030 Boxes Only 3
1
⁄4 Dia. 100
4051 — Round Blank or Pendant,
25
/64" Diameter Knockout 3
1
⁄4–4 Dia. 100
4052 BROWN — Round Flat Blank with 4" O.D. 3
1
⁄4–4 Dia. 100
4052 IVORY — Round Flat Blank with 4" O.D. 3
1
⁄4–4 Dia. 100
4052 WHITE — Round Flat Blank with 4" O.D. 3
1
⁄4–4 Dia. 100
4061 4.5 Round Plaster Ring,
1
⁄2" Offset for 3
1
⁄4 Mounting 4 Dia. 100
4062 BROWN — Round Flat Blank with 4
1
⁄2" O.D. 4 Dia. 100
4062 IVORY — Round Flat Blank with 4
1
⁄2" O.D. 4 Dia. 100
4062 WHITE — Round Flat Blank with 4
1
⁄2" O.D. 4 Dia. 100
Ceiling Boxes — Old Work
3051 4051 4052 Brown 4052 Ivory
