A-101
Phenolic Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
3090-94-40
3090-94
3190-C-94 3190-C-95
3090-95
4060-9402
4060-9502
4070-95
4070-95-PC
4070-95-404070-9502
4070-9402
4" Outlet Boxes with Bar Hanger
3
1
⁄2" Ceiling Box with Bar Hanger
4070-CFB-BHL
13.5–22.8 Cu. In.
CAT. NO. SIZE CU. IN. MOUNTING MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
3090-94 • 13.5 16" Bar Hanger, 12
1
⁄4" Min.–19" Max. High Clamps 3
1
⁄2 Dia. x 2
1
⁄8 D 50
3090-94-40 • 13.5 16" Bar Hanger, 12
1
⁄4" Min.–19" Max. High Clamps & #40 Ground Strap 3
1
⁄2 Dia. x 2
1
⁄8 D 50
3090-95 • 13.5 24" Bar Hanger, 16
1
⁄2" Min.–27" Max. High Clamps 3
1
⁄2 Dia. x 2
1
⁄8 D 50
3090-95-40 • 3.5 24" Bar Hanger, 16
1
⁄2" Min.–27" Max. High Clamps & #40 Ground Strap 3
1
⁄2 Dia. x 2
1
⁄8 D 50
3190-C-94 • 22.8 16" Bar Hanger High Clamps 3
1
⁄2 Dia. x 2
1
⁄8 D 25
3190-C-95 • 22.8 24" Bar Hanger High Clamps 3
1
⁄2 Dia. x 2
1
⁄8 D 25
• Listed for fixture support up to 50 lbs.
13.5–20.8 Cu. In.
CAT. NO. SIZE CU. IN. MOUNTING MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
4060-9402 • 13.5 16" Bar Hanger #36 Clamps, Bulk Packed 4 Dia. x 1
5
⁄8 D 50
4060-9502 • 13.5 24" Bar Hanger #36 Clamps, Bulk Packed 4 Dia. x 1
5
⁄8 D 50
4070-94 • 20.8 16" Bar Hanger, 12
1
⁄4" Min.–19" Max. High Clamps 4 Dia. x 2
3
⁄8 D 50
4070-9402 • 20.8 16" Bar Hanger, 12
1
⁄4" Min.–19" Max. #36 Clamps, Bulk Packed 4 Dia. x 2
3
⁄8 D 50
4070-95 • 20.8 24" Bar Hanger, 16
1
⁄2" Min.–27" Max. High Clamps 4 Dia. x 2
3
⁄8 D 50
4070-9502 • 20.8 24" Bar Hanger, 16
1
⁄2" Min.–27" Max. #36 Strap, Bulk Packed 4 Dia. x 2
3
⁄8 D 50
4070-95-40 • 20.8 24" Bar Hanger, 16
1
⁄2" Min.–27" Max. Ground Strap 4 Dia. x 2
3
⁄8 D 50
4070-95-PC • 20.8 24" Bar Hanger, 16
1
⁄2" Min.–27" Max. Non-Metallic Clamps 4 Dia. x 2
3
⁄8 D 50
4070-CFB-BHL
†
20.8 24" Bar Hanger, 12" to 24" Maximum Center — 4
1
⁄16 Dia. x 2
3
⁄8 D 10
• Listed for fixture support up to 50 lbs.
†
UL Listed for support of light fixtures of up to 50 lbs. or ceiling fans up to 35 lbs.
3090-95-40
4070-94
