A-99
Phenolic Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
3090-N 3090-N-40 3090-N-S
3060 3190 3190-C
3190-PC
3030-02-40 3030 3030-02 3000 3000-PC3000-02
3030PC
Nail-On
Flanged
3
1
⁄ 2 " Nail-On 13.5–22.8 Cu. In.
CAT. NO. SIZE CU. IN. MOUNTING MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
3060
†
3.5 Nails or Screw Mount, 3
7
⁄16" O.D. See NEC-725-2, 725-51, 725-52, Class 2 3
1
⁄2 Dia. x
5
⁄8 D 100
3090-N • 13.5 “N" Bracket High Clamps 3
1
⁄2 Dia. x 2
1
⁄8 D 50
3090-N-40 • 13.5 “N" Bracket High Clamps & #40 Ground Strap 3
1
⁄2 Dia. x 2
1
⁄8 D 50
3090-N-S • 13.5 “N" Bracket with Screws High Clamps & #36 Clamps, Bulk Packed 3
1
⁄2 Dia. x 2
7
⁄8 D 50
3190 • 22.8 Compound Angled Nails #36 Clamps, Bulk Packed 3
1
⁄2 Dia. x 3
1
⁄4 D 50
3190-C • 22.8 Compound Angled Nails High Clamps 3
1
⁄2 Dia. x 3
1
⁄4 D 50
3190-PC • 22.8 Compound Angled Nails Non-Metallic Clamps 3
1
⁄2 Dia. x 3
1
⁄4 D 50
• Listed for fixture support up to 50 lbs.
†
Not UL Listed.
3
1
⁄ 2 " Flanged for Manufactured Housing 11.5–20.5 Cu. In.
CAT. NO. SIZE CU. IN. MOUNTING MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
3030-02-40 • 11.5
Screw Mount
(4
3
⁄8" O.D. Flange or Flash Ring)
Box O.D. 3
1
⁄2"
#36 Clamps, Bulk Packed & #40
Ground Strap
3
1
⁄2 Dia. x 1
3
⁄4 D 100
3030 • 14.0 High Clamps 3
1
⁄2 Dia. x 1
3
⁄4 D 100
3030-02 • 14.0 #36 Clamps, Bulk Packed 3
1
⁄2 Dia. x 1
3
⁄4 D 100
3030PC • 14.0 Non-Metallic Clamps 3
1
⁄2 Dia. x 1
3
⁄4 D 100
3000 • 20.5 High Clamps 3
1
⁄2 Dia. x 2
7
⁄8 D 50
3000-02 • 20.5 #36 Clamps, Bulk Packed 3
1
⁄2 Dia. x 2
7
⁄8 D 50
3000-PC • 20.5 Non-Metallic Clamps 3
1
⁄2 Dia. x 2
7
⁄8 D 50
• Listed for fixture support up to 50 lbs.
