Phenolic Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
4" Square Boxes Nail-On Brackets 16.0–30.0 Cu. In.
4020-1 4020-1-02
4000-1-UB
4000-02
4000-N02
4000-N
CAt. No. size Cu. iN. MouNtiNg MeANs DesCriptioN DiMeNsioNs (iN.)
stD.
CtN.
4020-1 16.0
1
⁄2" Raised Face Bracket for Wood/Steel Studs High Clamps 4
5
⁄16 L x 4
5
⁄16 W x 1
1
⁄4 D 50
4020-1-02 16.0
1
⁄2" Raised Face Bracket for Wood/Steel Studs #36 Clamps, Bulk Packed 4
5
⁄16 L x 4
5
⁄16 W x 1
1
⁄4 D 50
4000-02 30.0 Nails or Screws, Bulk Packed #36 Clamps, Bulk Packed 4
1
⁄4 L x 4
1
⁄4 W x 2
3
⁄8 D 50
4000-1-uB 30.0
1
⁄2" Raised Face Bracket for Wood/Steel Studs High Clamps 4
1
⁄4 L x 4
1
⁄4 W x 2
3
⁄8 D 50
4000-N 30.0 “N” Bracket High Clamps 4
1
⁄4 L x 4
1
⁄4 W x 2
3
⁄8 D 50
4000-N02 30.0 “N” Bracket with Nails #36 Clamps, Bulk Packed 4
1
⁄4 L x 4
1
⁄4 W x 2
3
⁄8 D 50
Plaster Rings and Covers for 4" Square Boxes
4041 4042-12 4043 4022-12
CAt. No.
size
Cu. iN. DesCriptioN DiMeNsioNs (iN.) stD. CtN.
4041 — 4" Square Flat Back 4
1
⁄4 L x 4
1
⁄4 W x 4
1
⁄4 D 100
4042-12 4.0 4" Square Single-Gang Plaster Ring,
1
⁄2" Offset 4
1
⁄4 L x 4
1
⁄4 W x 4
1
⁄4 D 100
4043 4.5 4" Square Plaster Ring for 3
1
⁄4" Fixture,
1
⁄2" Offset 4
3
⁄16 L x 4
3
⁄16 W x 4
3
⁄16 D 100
4022-12 7.0 4" Square Two-Gang Plaster Ring,
1
⁄2" Offset 4
3
⁄16 L x 4
3
⁄16 W x 4
3
⁄16 D 50
