A-96
Phenolic Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
7074-BH7074-02-BH
2004-BH
2004-02-BH
2004-238 2004-238-02
Four-Gang Brackets 48.0–60.0 Cu. In.
CAt. No. size Cu. iN. MouNtiNg MeANs DesCriptioN DiMeNsioNs (iN.)
stD.
CtN.
7074-02 BH 48.0 Side Bracket & Stabilizing Bar #36 Clamps, Bulk Packed 3
5
⁄16 L x 7
5
⁄8 W x 2
5
⁄8 D 10
7074 BH 48.0 Side Bracket & Stabilizing Bar High Clamps 3
5
⁄16 L x 7
5
⁄8 W x 2
5
⁄8 D 10
2004-02-BH 60.0 Side Bracket & Stabilizing Bar #36 Clamps, Bulk Packed 3
5
⁄8 L x 7
23
⁄32 W x 3
1
⁄16 D 10
2004-BH 60.0 Side Bracket & Stabilizing Bar High Clamps 3
5
⁄8 L x 7
23
⁄32 W x 3
1
⁄16 D 10
2004-238 60.0 Two
3
⁄8" Offset Brackets for Wood/Steel Studs High Clamps 3
5
⁄8 L x 7
23
⁄32 W x 3
1
⁄16 D 20
2004-238-02 60.0 Two
3
⁄8" Offset Brackets for Wood/Steel Studs #36 Clamps, Bulk Packed 3
5
⁄8 L x 7
23
⁄32 W x 3
1
⁄16 D 20
