A-95
Phenolic Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
1043-C1043
1063
1063-C
1063-C-SQ1043-C-SQ
Three-Gang Nail-On 42.9–58.5 Cu. In.
7073-2 7073-202 7073-238-02 6063-4026063-4
CAt. No. size Cu. iN. MouNtiNg MeANs DesCriptioN DiMeNsioNs (iN.)
stD.
CtN.
7073-2 35.5 #2 Bottom Bracket and Wire Support High Clamps 3
3
⁄16 L x 5
13
⁄16 W x 2
5
⁄8 D 100
7073-202 35.5 #2 Bottom Bracket and Wire Support #36 Clamps, Bulk Packed 3
3
⁄16 L x 5
13
⁄16 W x 2
5
⁄8 D 100
7073-238-02 35.5 Two
3
⁄8" Offset Brackets for Wood/Steel Studs #36 Clamps, Bulk Packed 3
3
⁄16 L x 5
13
⁄16 W x 2
5
⁄8 D 100
6063-4 37.0 Ears, #4 Swing Bracket High Clamps 3
3
⁄8 L x 5
13
⁄16 W x 2
1
⁄2 D 100
6063-402 37.0 Ears, #4 Swing Bracket #36 Clamps, Bulk Packed 3
3
⁄8 L x 5
13
⁄16 W x 2
1
⁄2 D 50
Three-Gang Brackets 35.5–37.0 Cu. In.
CAt. No. size Cu. iN. MouNtiNg MeANs DesCriptioN DiMeNsioNs (iN.)
stD.
CtN.
1043 42.9 Compound Angled Nails #36 Clamps, Bulk Packed 3
5
⁄8 L x 5
7
⁄8 W x 2
3
⁄4 D 20
1043-C 42.9 Compound Angled Nails High Clamps 3
5
⁄8 L x 5
7
⁄8 W x 2
3
⁄4 D 20
1043-C-sQ 42.9 Angled Screws High Clamps 3
5
⁄8 L x 5
7
⁄8 W x 2
3
⁄4 D 20
1063 58.5 Compound Angled Nails #36 Clamps, Bulk Packed 3
21
⁄32 L x 5
15
⁄16 W x 3
21
⁄32 D 20
1063-C 58.5 Compound Angled Nails High Clamps 3
21
⁄32 L x 5
15
⁄16 W x 3
21
⁄32 D 20
1063-C-sQ 58.5 Compound Angled Screws High Clamps 3
21
⁄32 L x 5
15
⁄16 W x 3
21
⁄32 D 20
