A-93
Phenolic Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
1032-UB
1052-UB1052-PC
1052-C1032-C 1052-C-SQ
1072 1072-C
2030-502 2030-702 2000-738 1250-112
Two-Gang Nail-On 27.5–40.5 Cu. In.
One-Gang Brackets 16.0–20.3 Cu. In.
CAt. No. size Cu. iN. MouNtiNg MeANs DesCriptioN DiMeNsioNs (iN.)
stD.
CtN.
2030-502 16.0
1
⁄2" Offset Bracket for Wood/Steel Studs — 3
5
⁄8 L x 2
1
⁄4 W x 2
3
⁄4 D 100
2030-702 16.0
1
⁄4" Offset Bracket for Wood/Steel Studs — 3
5
⁄8 L x 2
1
⁄4 W x 2
3
⁄4 D 100
2000-738 18.0
3
⁄8" Offset Bracket for Wood/Steel Studs — 3
5
⁄8 L x 2
1
⁄4 W x 2
3
⁄4 D 100
1250-112 20.3
1
⁄2" Offset Bracket for Wood/Steel Studs — 3
5
⁄8 L x 2
1
⁄4 W x 2
3
⁄4 D 50
CAt. No. size Cu. iN. MouNtiNg MeANs DesCriptioN DiMeNsioNs (iN.) stD. CtN.
1032-C 27.5 Compound Angled Nails High Clamps 3
5
⁄8 L x 4
1
⁄16 W x 2
11
⁄16 D 50
1032-uB 27.5 Compound Angled Nails #36 Clamps, Bulk Packed 3
5
⁄8 L x 4
1
⁄16 W x 2
11
⁄16 D 50
1052-C 32.5 Compound Angled Nails High Clamps 3
5
⁄8 L x 4
1
⁄16 W x 2
11
⁄16 D 50
1052-C-sQ 32.5 Angled Screws High Clamps 3
5
⁄8 L x 4
1
⁄16 W x 2
11
⁄16 DD 50
1052-pC 32.5 Compound Angled Nails Non-Metallic Clamps 3
5
⁄8 L x 4
1
⁄16 W x 2
11
⁄16 D 50
1052-uB 32.5 Compound Angled Nails #36 Clamps, Bulk Packed 3
5
⁄8 L x 4
1
⁄16 W x 2
11
⁄16 D 50
1072 40.5 Compound Angled Nails #36 Clamps, Bulk Packed 3
5
⁄8 L x 4
1
⁄16 W x 2
11
⁄16 D 50
1072-C 40.5 Compound Angled Nails High Clamps 3
5
⁄8 L x 4
1
⁄16 W x 2
11
⁄16 D 50
1072-C-sQ 40.5 Angled Screws High Clamps 3
5
⁄8 L x 4
1
⁄16 W x 2
11
⁄16 D 50
1072-pC 40.5 Compound Angled Nails Non-Metallic Clamps 3
5
⁄8 L x 4
1
⁄16 W x 2
11
⁄16 D 50
