A-92
Phenolic Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
1250-UB-S 1050-UB 1260 1260-S
1250-UB
2050-UB 2070 2030 1040 1240
CAt. No. size Cu. iN. MouNtiNg MeANs DesCriptioN DiMeNsioNs (iN.)
stD.
CtN.
2050-uB 9.0 Bottom Nails — 3
9
⁄16 L x 2
1
⁄4 W x 1
13
⁄16 D 100
2070 14.0 Bottom Nails — 3
9
⁄16 L x 2
1
⁄4 W x 2
5
⁄8 D 100
2030 16.0 Bottom Nails — 3
9
⁄16 L x 2
15
⁄32 W x 2
13
⁄16 D 100
1040 18.0 Compound Angled Nails — 3
9
⁄16 L x 2
1
⁄8 W x 3
1
⁄8 D 100
1240 18.0 Recessed Angled Nails — 3
11
⁄16 L x 2
1
⁄4 W x 3
5
⁄16 D 100
2000 18.0 Bottom Nails “Classic” 3
11
⁄16 L x 2
1
⁄4 W x 3
1
⁄8 D 100
CAt. No.
size Cu.
iN. MouNtiNg MeANs DesCriptioN DiMeNsioNs (iN.)
stD.
CtN.
1250-uB 20.3 Recessed Angled Nails — 3
7
⁄8 L x 2
3
⁄8 W x 3
3
⁄8 D 100
1250-uB-s 20.3 Recessed Angled Nails — 3
7
⁄8 L x 2
3
⁄8 W x 3
3
⁄8 D 100
1050-uB 21.0 Compound Angled Nails — 3
5
⁄8 L x 2
5
⁄16 W x 3
1
⁄2 D 50
1260 22.5 Recessed Angled Nails — 3
7
⁄8 L x 2
3
⁄8 W x 3
21
⁄32 D 50
1260-s 22.5 Recessed Angled Nails — 3
7
⁄8 L x 2
3
⁄8 W x 3
21
⁄32 D 50
New Fire Rating! Carlon
®
phenolic boxes can be installed in the
same stud cavity of a shared two-hour wall. They may also face
opposite directions with only a 3" horizontal separation — ideal
for multi-family construction!
Carlon
®
Brown Phenolic Boxes
• AllPhenolicboxesarelistedtoUL514C
• AllPhenolicboxesarelistedformasonrywalls
• AllPhenolicboxesareUL
®
Classifiedfor2-hr.firewall
and/orfireceiling
• AllPhenolicboxesmeetNEMAOS-2
• AllPhenolicboxesarepermissibleforusewith
90°Cconductors
• UL
®
FileE11461andR9140
One-Gang Nail-On 9.0–18.0 Cu. In.
2000
One-Gang Nail-On 20.3–22.5 Cu. In.
