Polycarbonate Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
Ceiling Boxes
All ceiling boxes are produced from a high heat-resistant material
developed specifically for fixture support applications.
• Meets NEMA OS-2
• UL Listed to UL 514C
N-423-C-V N-423-GC-V
3
1
⁄ 2 " 20.5 Cu. In.
CAT. NO.
SIZE
CU. IN. MOUNTING MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
N-321-C • 20.5 Angled Side Nails Molded Fast Clamps 3
1
⁄2 Dia. x 3
1
⁄8 D 50
N-321-GC • 20.5 Angled Side Nails Molded Fast Clamps, Ground Strap Installed 3
1
⁄2 Dia. x 3
1
⁄8 D 50
• Listed for fixture support up to 50 lbs.
4" 22.5 Cu. In.
CAT. NO.
SIZE
CU. IN. MOUNTING MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
N-423-C-V • 22.5 Angled Side Nails Molded V-Clamps 4 Dia. x 2
1
⁄2 D 50
N-423-GC-V • 22.5 Angled Side Nails Molded Fast Clamps 4 Dia. x 2
1
⁄2 D 50
• Listed for fixture support up to 50 lbs.
N-321-CN-321-GC
