Polycarbonate Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
345-N
345-LB
New Work Boxes
460-SB-24
460-LB
460-SB
Four-Gang Nail-On 60 Cu. In.
CAT. NO.
SIZE
CU. IN.
MOUNTING
MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
460-SB 60.0 Angled Side Nails
& Back Bracket
POSI-WEDGE
®
Cable Clamps
3
3
⁄4 L x
7
9
⁄16 W x 2
3
⁄4 D
10
460-SB-24 •* 60.0 Angled Side Nails
& Back Bracket
POSI-WEDGE
®
Cable Clamps
3
3
⁄4 L x
7
9
⁄16 W x 2
3
⁄4 D
10
• 24" adjustable bracket.
* Not UL Classified for fire wall and/or fire ceiling
Four-Gang Bracket 60 Cu. In.
CAT. NO.
SIZE
CU. IN.
MOUNTING
MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
460-LB 60.0 Steel Side
Brackets
POSI-WEDGE
®
Cable Clamps
3
3
⁄4 L x
7
9
⁄16 W x 2
3
⁄4 D
8
* Not UL Classified for fire wall and/or fire ceiling
Three-Gang Nail-On 45.0 Cu. In.
CAT. NO.
SIZE
CU. IN. MOUNTING MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
345-N 45.0 Angled Side Nails &
Steel Side Brackets
POSI-WEDGE
®
Cable
Clamps
3
3
⁄4 L x
5
13
⁄16 W x 2
3
⁄4 D
20
Three-Gang Bracket 45 Cu. In.
CAT.
NO.
SIZE
CU. IN. MOUNTING MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
345-LB 45.0 Steel Side Bracket for
Wood/Steel Studs
POSI-WEDGE
®
Cable
Clamps
3
3
⁄4 L x
5
13
⁄16 W x 2
3
⁄4 D
25
