Polycarbonate Boxes
Boxes & Covers — Carlon
®
Non-Metallic Boxes
120-LB 120-LBP
122-LB 122-LBP
118-LB
118-LBP
New Work Boxes
234-LB
234-N 234-NP
One-Gang Brackets 18.0–22.5 Cu. In.
CAT. NO.
SIZE
CU. IN.
MOUNTING
MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
118-LB 18.0 Molded Side Bracket
for Wood/Steel Studs
— 3
3
⁄4 L x
2
1
⁄4 W x 2
7
⁄8 D
100
118-LBP 18.0 Molded Side Bracket
for Wood/Steel Studs
POSI-SET
®
Fast-Set
3
3
⁄4 L x
2
1
⁄4 W x 2
7
⁄8 D
100
120-LB 20.3 Molded Side Bracket
for Wood/Steel Studs
— 3
3
⁄4 L x
2
1
⁄4 W x 3
3
⁄16 D
100
120-LBP 20.3 Molded Side Bracket
for Wood/Steel Studs
POSI-SET
®
Fast-Set
3
3
⁄4 L x
2
1
⁄4 W x 3
3
⁄16 D
100
122-LB 22.5 Molded Side Bracket
for Wood/Steel Studs
— 3
3
⁄4 L x
2
1
⁄4 W x 3
5
⁄8 D
100
122-LBP 22.5 Molded Side Bracket
for Wood/Steel Studs
POSI-SET
®
Fast-Set
3
3
⁄4 L x
2
1
⁄4 W x 3
5
⁄8 D
100
Two-Gang Nail-On 34.0 Cu. In.
CAT. NO.
SIZE
CU. IN.
MOUNTING
MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
234-N 34.0 Angled Side Rails POSI-WEDGE
®
Cable Clamps
3
3
⁄4 L x
4 W x 3
3
⁄32 D
50
234-NP 34.0 Angled Side Rails POSI-WEDGE
®
POSI-SET
®
3
3
⁄4 L x
4 W x 3
3
⁄32 D
50
Two-Gang Bracket 34.0 Cu. In.
CAT. NO.
SIZE
CU. IN.
MOUNTING
MEANS DESCRIPTION DIMENSIONS (IN.)
STD.
CTN.
234-LB 34.0 Steel Side Bracket
for Wood/Steel Studs
POSI-WEDGE
®
Cable Clamps
3
3
⁄4 L x
4 W x 3
3
⁄32 D
50
