User guide

2. Installation
2.1 Installation Diagram
Monitor
Original LCD Cable
CAN
※ Connect Interface CAN1-High(Red) with
Car’s Brown+Red wire
※ Connect Interface CAN1-LOW(Brown( with
Car’s Brown wire
※ User can find Car’s Can wires behind Audio deck
CAN LOW
CAN HIGH
Provided LCD Cable
Provided TOUCH Cable
Behind of monitor
Touch screen
Command
-6-
Provided LVDS Cable
Navigation
Touch cable
X+
Y+
X-
Y-
AV1 AV2 AV3
REAR C
Audio L
Audio R
AV/OUT
Video
B DATA (blue) SYNC GND
IR-DTV
NAVI-VS
IR-NAVI
IR-DVD
R DATA (red) G DATA (green)
POWER cable
ACC
CAN1-
H
AUX-IN(L)
AUX-GND
A OUT(R)
CAN2-
H
GND
AUX-IN(R)
A OUT(L)
CAN1-L
CAN2-L
