User guide

1. Specifications
1.1 Main Specifications
1. Car Compatibility
New A-Class, B-Class, C-Class, E-Class, GLK-Class, ML-Class,
CLA-Class(Round connector Type)
2. Components
Interface* 1EA
3. MULTIMEDIA INTERFACE input specification
3 * A/V input (video external input)
1 * CVBS(Rear Camera) input
2 * Analog RGB input (Navigation system, HDMI)
1 * LCD input (Car system input)
4. MULTIMEDIA INTERFACE output specification
-1-
4. MULTIMEDIA INTERFACE output specification
1 * LCD output
5. Power specification
Input power : 8VDC ~ 18VDC
Consumed power : 5WATT
6. Switch input mode
- External display skip function : through DIP switch, can control
each video input
- Through remote control, can change input mode
- Through CAN or rear lamp cable, rear camera can be
detected
