User guide

3. Settings
3.1 DIP Switch
PIN
PINPIN
PINPIN
PINPIN
PIN Function
FunctionFunction
FunctionFunction
FunctionFunction
Function
Dip S/W SelectionDip S/W Selection
※ Example DIP S/W usage
- Use input mode : A/V2, A/V3
- Use original navigation
- External rear camera
▷DIP S/W : 1  ON (hide INPUT MODE)
▷DIP S/W : 2,3  OFF (A/V1,2 display)
▷DIP S/W : 4  OFF (A/V3 display)
▷DIP S/W : 5  OFF (High Resolution Monitor)
▷DIP S/W : 6  OFF
▷DIP S/W : 7  ON (display external rear cam)
▷DIP S/W : 8  OFF
※
※※
※ ON : DOWN / OFF : UP
󱺾󱋚󱧋
󱺾󱋚󱧋󱺾󱋚󱧋
󱺾󱋚󱧋 : 8󰸾
󰸾󰸾
󰸾 OFF
-9-
1
Displaying RGB input
ON : RGB mode skip
OFF : RGB mode display
2
Displaying A/V 1
ON : A/V 1 mode skip
OFF : A/V1 mode display
3
Displaying A/V 2
ON : A/V 2 mode skip
OFF : A/V2 mode display
4
Displaying A/V 3
ON : A/V 3 mode skip
OFF : A/V3 mode display
5
Setup of monitor size
ON : Low resolution monitor
OFF : High resolution monitor
6
N.C
7
Setup of rear camera use
ON : CVBS4
OFF : MAIN
8
Reset factory settings
(not use for user)
ON : Product factory reset
OFF : DEFAULT
