User Manual

ASSEMBLY
4
MODEL NO. 088- 2034
Step 1
Requires
2, 3, A, B.
Attach metal leg 2 to the metal center ring 3. Do not tighten completely,
Repeat procedure for the remaining three legs. Note
：
Make sure the
arrows “
↑
” pointing the same direction.
Step 2
Requires
1, 2, A, B.
Attached the frame 2 & 3 to the table top 1. Do not tighten completely,
Repeat procedure for the remaining three legs. Turn the table over. Tighten all
bolts in a diagonal pattern. Adjusting the table level by twisting knobs on the
bottom of the legs. Now your table is ready for use.
2
3
2
3
A
A
Not shown at actual size
remove from the metal leg
B
remove from the metal leg
1
2
2
1
A
x 4
x 4
A
Not shown at actual size
remove from the tabletop
B
x 16
x 16
remove from the tabletop
