User manual

Control Panel
Set./Adj. Menu
Setting Item Description, Instructions
Nozzle Check Print a test pattern to check the nozzles.
Status Print Print information about the printer .
Interface Print Print interface settings information.
GL2 Set Print Print GL2 settings information.
Paper Details Print the paper settings as specied in Paper Details .
Print Job Log Print a record of print jobs, including the paper type
and size, amount of ink consumed, and so on. Ink
consumption indicates a rough estimate of how much
ink was consumed per page.( *1 )
Menu Map Print the menu structure.
T est
Print
Color Palette Print the GL2 color palette.
Auto(Standard) The printer prints and reads a test pattern for the
automatic adjustment of Printhead alignment relative
to the printing direction.
( → P .604)
Auto(Advanced) The printer prints and reads a test pattern for the
automatic adjustment of Printhead alignment relative
to the printing direction and spacing between nozzles
and colors.
( → P .604)
Head
Posi.
Adj.
Manual Print a test pattern for adjustment of Printhead
alignment relative to the printing direction. Enter the
adjustment value manually based on the resulting
pattern.
( → P .606)
Head Inc. Adj. Print a test pattern for adjustment of the Printhead
orientation.
( → P .608)
Automatic
Print Quality
Adj.
Priority
Print Length
Specify exact paper feeding, if desired. Normally ,
select Automatic . Choose Print Quality for attractive
printing. Choosing Print Quality also makes banding
less noticeable. Choose Print Length if you prefer to
feed the paper an exact amount. However , note that
slight banding may occur in the direction of carriage
scanning when Print Length is selected.
Adjust
Printer
Feed
Priority
Adj.
Quality
Auto(GenuinePpr) Specify this mode with paper identied in the Paper
Reference Guide .
The printer prints and reads a test pattern for
automatic adjustment of the feed amount.
( → P .614)
52 Printer Parts
