Adjusting the Printhead
T roubleshooting Paper Abrasion and Blurry Images
(Head Height)
If the Printhead rubs against paper during printing, adjusting the Printhead height may improve results.
If image edges are blurred, it may help to lower the Printhead .
Note
• Raise or lower the printhead, depending on the nature of the problem.
( → P .670)
( → P .671)
( → P .676)
1. On the T ab Selection screen of the Control Panel , press ◄ or ► to select the Paper tab ( ).
Note
• If the T ab Selection screen is not displayed, press the Menu button.
2. Press the OK button.
The Paper Menu is displayed.
3. Press ▲ or ▼ to select Paper Details , and then press the OK button.
4. Press ▲ or ▼ to select the type of paper , and then press the OK button.
5. Press ▲ or ▼ to select Head Height , and then press the OK button.
6. Press ▲ or ▼ to select the desired setting value, and then press the OK button.
Note
• Depending on the type of paper , some setting values may not be available.
Adjustments for Better Print Quality 61 1
