User manual

Free Layout
Format Dialog Box
This dialog box appears when you select “Format” from the “Object” menu after you select an object.
“Size” Sheet
Y ou can rotate, enlarge, or reduce an object.
Note
• When the objects are not selected, you can not select “Format” .
“Rotate”
When you place a checkmark here, you can select “Rotate Right” or “Rotate Left” .
Setting
Details
“Rotate Right” Rotates the object 90 degrees clockwise.
“Rotate Left” Rotates the object 90 degrees counterclockwise.
Note
• When several objects are selected, you cannot select “Rotate” .
“Enl./Red.”
When you place a checkmark here, you can select “Scaling” , “Fit Paper Size” , or “Fit Photo Size” .
Setting
Details
“Scaling” Allows you to input the value of the enlargement or reduction ratio of an
object.
“Fit Paper Size” Prints by enlarging or reducing each object to match the paper size. If you
are using roll paper , objects are enlarged or reduced so that the width of
each object matches the width of the roll paper .
“Fit Photo Size” Prints all of the objects at the specied photo size.
Note
• Y ou can input between 25 and 600.
• Y ou can change the numbers by clicking either “▲” button or “▼” button.
