User manual

Handling rolls
Keeping T rack of the Amount of Roll Paper Left
Setting ManageRemainRoll to On in the Paper Menu of the Control Panel will print a barcode with text on the roll
when the roll is removed that identies the type of paper and amount left. When ManageRemainRoll is On and
you load rolls with printed barcodes, the type of paper and amount left are automatically detected after rolls are
loaded. The barcode will be cut of f after it has been read.
Important
• Because the ManageRemainRoll function is not compatible with clear lm, an error message may be
displayed ( The roll is empty . ) after you load clear lm. For this reason, set ManageRemainRoll to
Off before loading clear lm.
• If the barcode on the roll is not detected, enter the type and length of paper on the Control Panel .
Follow these steps to set ManageRemainRoll to On as follows.
1. On the T ab Selection screen of the Control Panel , press ◄ or ► to select the Paper tab ( ).
Note
• If the T ab Selection screen is not displayed, press the Menu button.
2. Press the OK button.
The Paper Menu is displayed.
3. Press ▲ or ▼ to select ManageRemainRoll , and then press the OK button.
4. Press ▲ or ▼ to select On , and then press the OK button.
126 Handling Paper
