<< Previous Next >> Installing Your Multifunction to Additional Computers on Your Network PIXMA MG5420 Macintosh OS 1
<< Previous Next >> Installing Your Multifunction to Additional Computers on Your Network PIXMA MG5420 Macintosh OS Preparing to Connect My Multifunction to My Network Network Requirements Notes on Wireless Connection Installing the Drivers 3 3 4 5 2
Preparing to Connect My Multifunction To My Network << Previous Next >> Network Requirements Before connecting the machine to the network, make sure that configuration of the computer and access point or router is complete, and that the computer is connected to the network. Wireless Connection Before connecting the machine to the network, the computer needs to be connected to the network. Make sure that configuration of the computer and access point or router is complete.
Preparing to Connect My Multifunction To My Network << Previous Next >> An "Ad-hoc connection," which establishes a direct connection to the computer over a wireless connection without using an access point, is not supported. A router or access point is required for your printer to be used on a wireless network. Notes on Network Connection • The configuration, router functions, setup procedures and security settings of the network device vary depending on your system environment.
Installing the Drivers & Software << Previous Next >> Software Installation To use the machine by connecting it to a computer, software including the drivers needs to be copied (installed) to the computer's hard disk. (The installation time varies depending on the computer environment or the number of application software to be installed.) IMPORTANT • Log on as the administrator (or a member of the Administrators group). • Quit all running applications before installation.
Installing the Drivers << Previous Next >> Installing the PIXMA MG5420 to additional Mac computers on your Wireless Network If your MG5420 has already been set up for on your wireless network , it is only necessary to install the software on the additional computer(s). Connection to the network is confirmed automatically. It is not necessary to make any changes or settings on the printer itself. The printer does not have to be reset or connected via USB cable to the additional computer(s).
Installing the Drivers << Previous Next >> 1. Insert the CD-ROM into the computer. IMPORTANT If the USB cable is already connected, unplug it. If a message appears on the computer, click Cancel. 2. Double-click the Setup icon in the CD-ROM folder, then click Download in the subsequent window.
Installing the Drivers << Previous Next >> REFERENCE •When the CD-ROM folder does not open automatically, double-click the CD-ROM icon displayed on the desktop. •The screen below is displayed while downloading.
Installing the Drivers << Previous Next >> If you click Cancel while downloading, you will see the following screen. - If you click No, you will return to the screen displayed while downloading. - If you click Yes, the download is cancelled. In this case, the files under the download are deleted. When the download fails, the screen below is displayed. Click OK, and you will go back to the screen for downloading in the procedure .
Installing the Drivers << Previous Next >> 3. When the download is complete, the screen below is displayed. Click Next. REFERENCE Select "Save a file for setting up the software again to the download folder after the installation is complete," and the file will be saved to the download folder.
Installing the Drivers << Previous Next >> You can perform the setup later using this file. 4. In the subsequent screen, enter the administrator name and password. Then click OK.
Installing the Drivers 5. Click Next << Previous Next >> 6. Continue to follow instructions. On the Software Installation List screen, select any additional software* you wish to install, then click Next *MP Drivers and Canon IJ Network Tool which are pre-selected are required for wireless network connection. We recommend also installing ScanGear , My Image Garden and Quick Menu to enjoy all the features of the printer.
Installing the Drivers << Previous Next >> Add the Printer 1.
Installing the Drivers << Previous Next >> 2. Select Canon MG5400 series with Canon IJ Network listed in the Kind* column. Click Add. REFERENCE If the machine is not detected, make sure of the following: - The machine is turned on. - The firewall function of any security software is turned off. -The computer is connected to the access point.
Installing the Drivers 4. Click Next. << Previous Next >> 5. Click Next.
Installing the Drivers using downloaded files << Previous If you can’t find your CD-ROM, you can set up the printer by downloading and installing the MG5400 series Mini Master Setup, which includes the same step-by-step installation as the CD-ROM. Follow the instructions below: 1. Click here to access the MG5420 Drivers & Software page. 2. Select the operating system and version of your computer (see example below). 3. Expand the ‘Drivers’ section, if necessary, by clicking the red triangle. 4.
Installing the Drivers using downloaded files << Previous 5. Once the download is complete, double-click the file from its download location to begin the installation. 6. Click the Setup icon 7. Follow the same instructions as installing from the CD-ROM beginning with Step 5.
