Section B. SYSTEM DESCRIPTION
This system (D.U.T.) is an 700MHz Signal Booster to operate within range 763-
775 MHz (DL path), 793-805 MHz (UL path) for Land Mobile radio FCC Part 90.
The system features eight or more programmable frequency narrowband
filters. The desired operation frequencies must be configured using built-in
Web Server.
Programmable Individual Rx Threshold level (Squelch) per filter allows
transmission if the probe signal is greater than configured Squelch.
Individual Automatic Gain Control (AGC) per filter delivers constant output
power level per channel (+/- 1 dB) regardless of their input level variations.
The maximum output level per filter can be changed with option “Maximum
Desired Output Level per filter” in Main Settings page from Web Server
The built-in Web Server provides a Graphical User Interface (GUI) to ease in
remote monitoring & control. Access is obtained via a PC’s Web Browser
and a TCP/IP connection to the Unit. The system can be connected directly
to a PC computer or can be plugged into the local area network.
Some pages shown by the Web Server are the following:
“Main Status”: depicts status alarm indicators and meters.
“Main Settings”: is used to configure system-level macro settings.
“Filter Settings” contains the settings that can be configured for each
filter window.
Never operate the system without adequate Load/Termination on the
Donor/Base and Service/Side T/R port. The 700 MHz Signal Booster will amplify
until 120dB gain any input stimulus greater than Rx Threshold level (Squelch).
The Web Server allows to Mute/Un-mute Power Amplifiers in “Main Settings”
page. Make sure the power amplifiers are un-muted before start with the
test.
