CSIM11 pH and ORP Probes
7.3 Wiring
The CSIM11 and CSIM11-ORP are connected to differential channels.
Connections to Campbell Scientific dataloggers are given in TABLE 7-1.
TABLE 7-1. CSIM11/CSIM11-ORP Wiring
Color
Description
CR9000(X)
CR5000
CR3000
CR1000
CR800
CR850
CR510
CR500
CR10(X)
21X
CR7
CR23X
Red Signal Differential
High
Differential
High
Differential
High
Green Signal
Reference
Differential
Low
Differential
Low
Differential
Low
Brown Signal Ground AG
Often Campbell Scientific’s 107 temperature probe is used to compensate for
thermal effects. TABLE 7-2 shows the connections to the 107 probe.
TABLE 7-2. 107 Wiring
Color
Description
CR9000(X)
CR5000
CR3000
CR1000
CR800
CR850
CR510
CR500
CR10(X)
21X
CR7
CR23X
Black Voltage
Excitation
EX or VX EX EX
Red Temperature
Signal
Single-ended
channel
Single-ended
channel
Single-ended
channel
Purple Signal Ground AG
Clear Shield G
7.4 Datalogger Programming
Short Cut is the best source for up-to-date datalogger programming code.
Programming code is needed,
• when creating a program for a new datalogger installation
• when adding sensors to an existing datalogger program
If your data acquisition requirements are simple, you can probably create and
maintain a datalogger program exclusively with Short Cut. If your data
acquisition needs are more complex, the files that Short Cut creates are a great
source for programming code to start a new program or add to an existing
custom program.
