Appendix B. 43502 Aspirated Radiation Shield

Grommet

Sensor

Mounting

Bushing

FIGURE B-1. 43347 probe and bushing

Wiring:

TACH – White

POS – Red

EG – Black

FIGURE B-2. 43347 probe mounted inside the 43502 shield

B-2
