User's Manual

5-2
Part No. 001-4008-101/102
Table 5-2 Normal Factory Settings (Bases)
Refer to help files for descriptions of the above fields.
Fields
Full Duplex Base Integra-TR with
other Integra-TR
Redundant Integra-TR Full Duplex
Base with Integra-TR/ Integra-T
RX Unit TX Unit Rx Units TX Units
Network Settings
Compatibility Mode Integra-TR Integra-TR and Integra-T
Tx/Rx Mode Rx Only Tx Only Rx Only Tx Only
Extended Preamble (ms) 0
Network Speed 19200 Full Channel, 9600 Half Channel,
or 2400 Quarter Channel
9600 Full Channel
Tx Time Out Disable
Tx Online Diagnostics Yes
Unit Type Master
Data Delivery All
Suspend Period (ms) 0
Activity Time-out (sec) 5
Sleep Mode Disable (N/A)
COM Port
Device Baud 19200 9600
Data fwd timer Normal
Parity 8 bit, no parity, 1 stop bit
Break Ignore break
Xmit Control DOX
ActiveDCD Control
Analog Connector
Analog 1 Input Fan Control Input Fan Control
Analog 2 RxTp Input RxTp Ant. SW Control
Frequency
Transmit User Choice
Receive User Choice
Adjustments
Carrier Sense (-dBm) 105 (N/A) 110 (N/A)
Power Out 255 (indicates 5 Watts nominal)
Frequency Warp Grayed out (radio dependant) Values are set at factory; can be changed if required; hit
release test button to enable fieldDeviation
