User's Manual

SECTION 5
CONFIGURABLE PARAMETERS
5-1
001-4008-101/102
5.1 PARAMETER OVERVIEW
The parameters used to configure the Integra-TR units are described in the Field Programming Software
help file. Section 5 summarizes the Integra-TR parameter settings and their variations when used within a
network.
Refer to help files for descriptions of the above fields.
Table 5-1 Normal Factory Settings (Units)
Fields
Integra-TR with other
Integra-TR
Integra-TR with Integra-T Integra T
Network Settings
Compatibility Mode Integra-TR Integra-TR & Integra-T (N/A)
Tx/Rx Mode Both Tx and Rx (N/A)
Extended Preamble (ms) 0
Network Speed 19200 Full Channel,
9600 Half Channel, or
2400 Quarter Channel
9600 Full Channel
Tx Time Out 30 sec ON
Tx Online Diagnostics Yes
Unit Type Master
Data Delivery All
Suspend Period (ms) 0
Activity Time-out (sec) 5
Sleep Mode Disable (N/A)
COM Port
Device Baud 19200 9600
Data fwd timer Normal
Parity 8 bit, no parity, 1 stop bit
Break Ignore break
Xmit Control DOX
DCD Control Active
Analog Connector
Analog 1 Input or Fan Control
(Units with cooling option)
Input
Analog 2 Input
Frequency
Transmit User choice
Receive User choice
Adjustments
Carrier Sense (-dBm) 105 110
Power Out 255 (indicates 5 Watts nominal)
Frequency Warp Grayed out (radio dependent)
Values set at factory can be changed, if required; hit related test button to
enable field
Deviation
RXA Adjust
