PCB Information 7.2.3

Ref Var IPN Description Ref Var IPN Description

D3 001-00011-60 (S) DIODE SR2607 6A/30V

D4 001-10000-70 (S) DIODE SMD BAV70 DUAL SWITCH SOT-23 CO

D6 001-10000-70 (S) DIODE SMD BAV70 DUAL SWITCH SOT-23 CO

D13 001-10000-70 (S) DIODE SMD BAV70 DUAL SWITCH SOT-23 CO

FTC 012-04100-05 CAP F/THRU 1N SUPPR FLTR STUD MTG

(fan circuit; mounted on heatsink)

IC1 002-10003-24 (S) IC SMD 324 QUAD OP AMP SO14

IC2 002-00014-62 (S) IC 317L 100MA REG 3 TERMINAL TO-92

IC3 002-10003-24 (S) IC SMD 324 QUAD OP AMP SO14

IC4 002-00014-62 (S) IC 317L 100MA REG 3 TERMINAL TO-92

IC5 002-10003-58 (S) IC SMD LM358 DUAL OP AMP

L1 051-00626-00 COAX 1/4 WAVE XFMR 35E HELI LEFT HAND

L3 065-10004-20 BEAD FE SMD CBD 4.6/3/3-4S2

L4 051-00005-28 COIL TAIT NO 528 HAIRPIN 17MM T550A

L5 052-08160-55 COIL A/W 5.5T/6.0MM HOR 0.8MM WIRE

L6 065-10004-20 BEAD FE SMD CBD 4.6/3/3-4S2

L8 065-10004-20 BEAD FE SMD CBD 4.6/3/3-4S2

L9 051-00005-60 IND HAIRPIN 10MM TALL T859

L10 052-08160-55 COIL A/W 5.5T/6.0MM HOR 0.8MM WIRE

L12 051-00623-00 COAX 1/4 WAVE XFMR 25E HAIR PIN

L13 051-00619-00 COUPLER WIRELINE 800MHZ (53MM JACKET ST

L14 051-00619-00 COUPLER WIRELINE 800MHZ (53MM JACKET ST

L15 051-00619-00 COUPLER WIRELINE 800MHZ (53MM JACKET ST

L16 051-00629-00 COAX 1/4 WAVE XFMR 35E HOCKEY STICK RIGH

L18 065-10004-20 BEAD FE SMD CBD 4.6/3/3-4S2

L19 051-00005-60 IND HAIRPIN 10MM TALL T859

L20 052-08160-55 COIL A/W 5.5T/6.0MM HOR 0.8MM WIRE

L22 051-00624-00 COAX 1/4 WAVE XFMR 25E HOCKEY STICK LEFT

L26 051-00627-00 COAX 1/4 WAVE XFMR 35E HELI RIGHT HAND

L28 065-10004-20 BEAD FE SMD CBD 4.6/3/3-4S2

L29 051-00005-60 IND HAIRPIN 10MM TALL T859

L30 052-08160-55 COIL A/W 5.5T/6.0MM HOR 0.8MM WIRE

L32 051-00621-00 COAX 1/4 WAVE XFMR 25E HELI LEFT HAND

L33 051-00626-00 COAX 1/4 WAVE XFMR 35E HELI LEFT HAND

L35 065-10004-20 BEAD FE SMD CBD 4.6/3/3-4S2

L36 051-00005-60 IND HAIRPIN 10MM TALL T859

L37 052-08160-55 COIL A/W 5.5T/6.0MM HOR 0.8MM WIRE

L39 051-00622-00 COAX 1/4 WAVE XFMR 25E HELI RIGHT HAND

L40 051-00619-00 COUPLER WIRELINE 800MHZ (53MM JACKET ST

L41 051-00619-00 COUPLER WIRELINE 800MHZ (53MM JACKET ST

L42 051-00619-00 COUPLER WIRELINE 800MHZ (53MM JACKET ST

L43 051-00628-00 COAX 1/4 WAVE XFMR 35E HOCKEY STICK LEFT

L45 065-10004-20 BEAD FE SMD CBD 4.6/3/3-4S2

L46 051-00005-60 IND HAIRPIN 10MM TALL T859

L47 052-08160-55 COIL A/W 5.5T/6.0MM HOR 0.8MM WIRE

L49 051-00625-00 COAX 1/4 WAVE XFMR 25E HOCKEY STICK RIGH

L50 056-00021-04 IND FXD 330NH AXIAL

L51 056-00021-04 IND FXD 330NH AXIAL

L52 056-00021-04 IND FXD 330NH AXIAL

L53 052-08323-20 COIL A/W 2T/2.3MM SMD 0.8MM WIRE

L54 052-08325-20 COIL A/W 2T/2.5MM SMD 0.8MM WIRE

L55 052-08325-20 COIL A/W 2T/2.5MM SMD 0.8MM WIRE

L56 052-08323-20 COIL A/W 2T/2.3MM SMD 0.8MM WIRE

L60 065-10004-20 BEAD FE SMD CBD 4.6/3/3-4S2

L61 065-10004-20 BEAD FE SMD CBD 4.6/3/3-4S2

L63 052-56130-85 COIL A/W 8.5T/3.0MM HOR 0.56MM WIRE

L64 051-00630-00 LINK 15MM 1.4MM2 COPPER STAPLE

L65 051-00630-00 LINK 15MM 1.4MM2 COPPER STAPLE

L66 051-00630-00 LINK 15MM 1.4MM2 COPPER STAPLE

LED 008-00013-32 (S) LED 3MM RED LO CURRENT NO MTG (x2)

(front panel) 008-00013-35 (S) LED 3MM GREEN LO CURRENT NO MTG

LINK1 036-10000-00 RES M/F 0805 CHIP ZERO OHM

LINK2 036-10000-00 RES M/F 0805 CHIP ZERO OHM

P1 240-02100-44 SKT COAX MINI JACK PCB MTG ANGLED

Q1 000-00293-30 (S) XSTR 2SC2933 NPN EPITAXIAL PLANAR 900M

Q2 000-00141-40 (LS) XSTR SD1414 6LFL UHF 45W

Q3 000-00141-40 (LS) XSTR SD1414 6LFL UHF 45W

Q4 000-00141-40 (LS) XSTR SD1414 6LFL UHF 45W

Q5 000-00141-40 (LS) XSTR SD1414 6LFL UHF 45W

Q6 000-00141-40 (LS) XSTR SD1414 6LFL UHF 45W

Q10 000-10017-00 (LS) XSTR SMD MMBF170LT1 FET SOT23

Q11 000-10008-17 (S) XSTR SMD BC817-25 NPN SOT-23 AF LO PW

Q12 000-10017-00 (LS) XSTR SMD MMBF170LT1 FET SOT23

Q13 000-10008-17 (S) XSTR SMD BC817-25 NPN SOT-23 AF LO PW

Q15 000-10008-17 (S) XSTR SMD BC817-25 NPN SOT-23 AF LO PW

Q16 000-00030-95 (S) XSTR 2N6107 PNP TO-220 AF PWR

Q17 000-10008-57 (S) XSTR SMD BCW70/BC857-215 PNP SOT23 AF

Q18 000-00011-70 (S) XSTR BD136 PNP AF PWR TO126

Q19 000-10008-57 (S) XSTR SMD BCW70/BC857-215 PNP SOT23 AF

Q20 000-10008-17 (S) XSTR SMD BC817-25 NPN SOT-23 AF LO PW

Q21 000-10008-17 (S) XSTR SMD BC817-25 NPN SOT-23 AF LO PW

Q22 000-10008-48 (S) XSTR SMD BCW60/BC848B215 NPN SOT23 AF

Q23 000-10008-48 (S) XSTR SMD BCW60/BC848B215 NPN SOT23 AF

Q24 000-10008-57 (S) XSTR SMD BCW70/BC857-215 PNP SOT23 AF

Q25 000-10008-48 (S) XSTR SMD BCW60/BC848B215 NPN SOT23 AF

}

see

note

below

Note:

Fit two new grounding clips (IPN 319-40009-00) when

replacing SD1414 transistors (see Section 3.4.2).

R1 036-02100-03 L) RES 1218 PWR CHIP 10E 20% 1W

R2 036-02100-03 L) RES 1218 PWR CHIP 10E 20% 1W

R3 036-02100-02 RES 10E 1206 CHIP 200V 250MW RC01

R4 036-02100-03 L) RES 1218 PWR CHIP 10E 20% 1W

R5 036-02100-03 L) RES 1218 PWR CHIP 10E 20% 1W

R6 036-02100-02 RES 10E 1206 CHIP 200V 250MW RC01

R7 039-01650-00 RES DUMP LOAD 50E 16W TO-220

R8 039-05025-00 RES DUMP LOAD 25E 50W TO-220

R9 039-01650-00 RES DUMP LOAD 50E 16W TO-220

R10 036-02100-03 L) RES 1218 PWR CHIP 10E 20% 1W

R11 036-02100-03 L) RES 1218 PWR CHIP 10E 20% 1W

R12 036-02100-03 L) RES 1218 PWR CHIP 10E 20% 1W

R13 036-02100-03 L) RES 1218 PWR CHIP 10E 20% 1W

R14 036-02100-03 L) RES 1218 PWR CHIP 10E 20% 1W

R15 036-02100-03 L) RES 1218 PWR CHIP 10E 20% 1W

R16 039-05025-00 RES DUMP LOAD 25E 50W TO-220

R17 039-05025-00 RES DUMP LOAD 25E 50W TO-220

R17A 039-05025-00 RES DUMP LOAD 25E 50W TO-220

R18 039-05025-00 RES DUMP LOAD 25E 50W TO-220

R19 036-02100-03 L) RES 1218 PWR CHIP 10E 20% 1W

R20 036-02100-03 L) RES 1218 PWR CHIP 10E 20% 1W

R21 036-02100-02 RES 10E 1206 CHIP 200V 250MW RC01

R22 030-53100-20 RES FILM AI 100E 5% 0.4W 4X1.6MM

R23 030-53100-20 RES FILM AI 100E 5% 0.4W 4X1.6MM

R24 036-02100-02 RES 10E 1206 CHIP 200V 250MW RC01

R29 036-02100-02 RES 10E 1206 CHIP 200V 250MW RC01

R36 036-13680-00 RES M/F 0805 CHIP 680E 5%

R37 036-14100-00 RES M/F 0805 CHIP 1K 5%

R37A 036-14100-00 RES M/F 0805 CHIP 1K 5%

R38 036-17100-00 RES M/F 0805 CHIP 1M 5%

R42 036-15100-00 RES M/F 0805 CHIP 10K 5%

RV43 042-05470-09 RES PRESET 50K CERMET 9.5MM SQ FLAT

R44 036-14470-00 RES M/F 0805 CHIP 4K7 5%

R47 036-16100-00 RES M/F 0805 CHIP 100K 5%

RV48 042-04500-08 RES PRESET 5K CERMET 9.5MM SQ FLAT

R49 036-13680-00 RES M/F 0805 CHIP 680E 5%

R50 036-13680-00 RES M/F 0805 CHIP 680E 5%

RV52 042-04500-08 RES PRESET 5K CERMET 9.5MM SQ FLAT

R55 036-17100-00 RES M/F 0805 CHIP 1M 5%

R56 036-15100-00 RES M/F 0805 CHIP 10K 5%

RV57 042-05470-09 RES PRESET 50K CERMET 9.5MM SQ FLAT

R57 036-03820-03 L) RES 1218 PWR CHIP 820E 20% 1W

R57A 036-03820-03 L) RES 1218 PWR CHIP 820E 20% 1W

R58 036-14470-00 RES M/F 0805 CHIP 4K7 5%

R59 036-01560-03 L) RES 1218 PWR CHIP 5E6 20% 1W

R59A 036-01560-03 L) RES 1218 PWR CHIP 5E6 20% 1W

R60 036-03820-03 L) RES 1218 PWR CHIP 820E 20% 1W

R60A 036-03820-03 L) RES 1218 PWR CHIP 820E 20% 1W

R61 036-13220-00 RES M/F 0805 CHIP 220E 5%

R62 036-14100-00 RES M/F 0805 CHIP 1K 5%

#RV63 044-04200-03 RES PRESET MULTITURN 2K 10T PNL MTG

R64 036-14470-00 RES M/F 0805 CHIP 4K7 5%

R65 036-16100-00 RES M/F 0805 CHIP 100K 5%

R66 036-16100-00 RES M/F 0805 CHIP 100K 5%

R67 036-15100-00 RES M/F 0805 CHIP 10K 5%

R68 036-14470-00 RES M/F 0805 CHIP 4K7 5%

RV69 042-04220-02 RES PRESET 2K CERMET 9.5MM SQ FLAT TOP A

R69 036-12100-00 RES M/F 0805 CHIP 10E 5%

R70 036-13220-00 RES M/F 0805 CHIP 220E 5%

R72 045-04470-01 RES NTC 4K7 5% 5MM DISC

R73 036-16220-00 RES M/F 0805 CHIP 220K 5%

RV74 042-06500-08 RES PRESET 500K CERMET 9.5MM SQ FLAT

R75 036-15100-00 RES M/F 0805 CHIP 10K 5%

R76 036-14470-00 RES M/F 0805 CHIP 4K7 5%

R77 036-14220-00 RES M/F 0805 CHIP 2K2 5%

R78 036-14100-00 RES M/F 0805 CHIP 1K 5%

R79 036-16100-00 RES M/F 0805 CHIP 100K 5%

R80 036-13100-00 RES M/F 0805 CHIP 100E 5%

R81 036-14100-00 RES M/F 0805 CHIP 1K 5%

R82 036-14220-00 RES M/F 0805 CHIP 2K2 5%

R83 036-14100-00 RES M/F 0805 CHIP 1K 5%

R84 036-14220-00 RES M/F 0805 CHIP 2K2 5%

R85 036-14100-00 RES M/F 0805 CHIP 1K 5%

R86 036-14100-00 RES M/F 0805 CHIP 1K 5%

R87 036-15100-00 RES M/F 0805 CHIP 10K 5%

R88 036-15100-00 RES M/F 0805 CHIP 10K 5%

R89 036-13100-00 RES M/F 0805 CHIP 100E 5%

R90 036-03100-02 RES 100E 1206 CHIP 200V 250MW RC01

R91 036-03330-03 L) RES 1218 PWR CHIP 330E 20% 1W

R92 036-03330-03 L) RES 1218 PWR CHIP 330E 20% 1W

R95 036-14100-00 RES M/F 0805 CHIP 1K 5%

R96 036-14470-00 RES M/F 0805 CHIP 4K7 5%

R97 036-14100-00 RES M/F 0805 CHIP 1K 5%

R98 036-15100-00 RES M/F 0805 CHIP 10K 5%

R99 036-14390-00 RES M/F 0805 CHIP 3K9 5%

R100 036-14100-00 RES M/F 0805 CHIP 1K 5%

R101 036-12100-00 RES M/F 0805 CHIP 10E 5%

R102 036-16220-00 RES M/F 0805 CHIP 220K 5%

R103 036-15330-00 RES M/F 0805 CHIP 33K 5%

R104 036-15150-00 RES M/F 0805 CHIP 15K 5%

R105 036-16470-00 RES M/F 0805 CHIP 470K 5%

R106 036-15150-00 RES M/F 0805 CHIP 15K 5%

R107 036-14390-00 RES M/F 0805 CHIP 3K9 5%

R108 036-15100-00 RES M/F 0805 CHIP 10K 5%

R109 036-14330-00 RES M/F 0805 CHIP 3K3 5%

R110 036-16100-00 RES M/F 0805 CHIP 100K 5%

R111 036-16220-00 RES M/F 0805 CHIP 220K 5%

R112 036-16220-00 RES M/F 0805 CHIP 220K 5%
