7.2.2 PCB Information

M889-00

02/10/95 Copyright TEL

T889 Parts List (IPN 220-01326-01)

How To Use This Parts List

The components listed in this parts list are divided into two main types: those with a circuit reference (e.g. C2, D1, R121, etc) and

those without (miscellaneous and mechanical).

Those with a circuit reference are grouped by component type in numerical order. Each component entry comprises three or four col-

umns: the circuit reference, variant number (if applicable), IPN and description. A number in the variant column indicates that this

component is fitted only to that variant.

The miscellaneous and mechanical section lists the variant and common parts in IPN order.

Parts List Amendments

Although shown in the parts list, PCB layout and circuit diagrams, R57A, R59A and R60A are not fitted (to increase the drive to Q1).

Ref Var IPN Description Ref Var IPN Description

C1 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2.

C2 029-02120-02 CAP MICA 5MM CASE 12P 5%

C3 029-02120-02 CAP MICA 5MM CASE 12P 5%

C6 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2.

C7 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C9 029-02100-02 CAP MICA 5MM CASE 10P 5%

C10 015-01680-02 CAP CER HIQ 1210 CHIP 6P8 5% NPO 200V

C11 015-02120-03 CAP CER CHIP 12P 5% 500V HIQ GRH111 2.8MM

C12 015-02120-03 CAP CER CHIP 12P 5% 500V HIQ GRH111 2.8MM

C13 029-02200-02 CAP MICA 5MM CASE 20P 5%

C14 029-02220-02 CAP MICA 5MM CASE 22P 5%

C15 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C16 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C17 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C18 014-07470-03 L) CAP TANT CHIP 4U7 25V +-20% 6X3.2X2.5M

C19 029-02120-02 CAP MICA 5MM CASE 12P 5%

C20 015-02150-03 CAP CER CHIP 15P 5% 500V HIQ GRH111 2.8MM

C21 015-02120-03 CAP CER CHIP 12P 5% 500V HIQ GRH111 2.8MM

C22 029-02220-02 CAP MICA 5MM CASE 22P 5%

C23 029-02220-02 CAP MICA 5MM CASE 22P 5%

C24 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C25 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C26 015-02150-03 CAP CER CHIP 15P 5% 500V HIQ GRH111 2.8MM

C27 015-02120-03 CAP CER CHIP 12P 5% 500V HIQ GRH111 2.8MM

C28 029-02220-02 CAP MICA 5MM CASE 22P 5%

C29 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C30 029-02220-02 CAP MICA 5MM CASE 22P 5%

C31 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C32 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C33 015-02150-03 CAP CER CHIP 15P 5% 500V HIQ GRH111 2.8MM

C34 015-02120-03 CAP CER CHIP 12P 5% 500V HIQ GRH111 2.8MM

C35 029-02220-02 CAP MICA 5MM CASE 22P 5%

C36 029-02220-02 CAP MICA 5MM CASE 22P 5%

C37 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C38 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C39 014-07470-03 L) CAP TANT CHIP 4U7 25V +-20% 6X3.2X2.5M

C40 015-02150-03 CAP CER CHIP 15P 5% 500V HIQ GRH111 2.8MM

C41 015-02120-03 CAP CER CHIP 12P 5% 500V HIQ GRH111 2.8MM

C42 029-02220-02 CAP MICA 5MM CASE 22P 5%

C43 029-02220-02 CAP MICA 5MM CASE 22P 5%

C44 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C45 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C46 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C47 014-07470-03 L) CAP TANT CHIP 4U7 25V +-20% 6X3.2X2.5M

C48 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V

C50 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C51 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C52 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V

C53 029-01270-02 CAP MICA 5MM CASE 2P7 +-0.25P

C54 029-01560-01 CAP MICA 10MM CASE 5P6 +-0.25P

C55 029-01680-01 CAP MICA 10MM CASE 6P8 5%

C56 029-01560-01 CAP MICA 10MM CASE 5P6 +-0.25P

C57 029-01270-02 CAP MICA 5MM CASE 2P7 +-0.25P

C58 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C59 014-07470-03 L) CAP TANT CHIP 4U7 25V +-20% 6X3.2X2.5M

C60 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V

C61 014-07470-03 L) CAP TANT CHIP 4U7 25V +-20% 6X3.2X2.5M

C62 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V

C64 015-01330-06 CAP CER 1210 CHIP 3P3 NPO 500V GRM42-2

C65 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C66 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C67 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C68 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C69 014-08100-00 CAP TANT CHIP 10M 16VW +-20% 6X3.2X2.5MM

C70 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C71 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C72 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C73 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C74 015-02470-03 CAP CER CHIP 47P 5% NPO 500V HIQ GRH111 2

C76 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V

C77 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C78 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C81 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C84 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V

C85 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C87 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C88 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C89 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C90 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C91 014-08100-00 CAP TANT CHIP 10M 16VW +-20% 6X3.2X2.5MM

C92 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V

C93 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C94 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V

C95 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C96 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C97 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C98 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V

C99 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C102 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C103 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C104 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V

C105 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C106 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C107 014-07100-02 CAP TANT CHIP 1U0 3.2 X 1.6MM 267 SERIES

C108 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C109 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C114 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C115 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C116 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C117 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C118 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C119 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C120 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C121 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C122 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C123 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C124 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C125 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C126 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C127 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C128 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C129 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C130 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C131 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V

C132 014-07470-03 L) CAP TANT CHIP 4U7 25V +-20% 6X3.2X2.5

D1 001-00013-45 (S) DIODE SCHOTTKY 1SS97/2

D2 001-00013-45 (S) DIODE SCHOTTKY 1SS97/2
