7.1.4 PCB Information
M889-00
02/10/95 Copyright TEL
the line to indicate where the rest of the circuitry is located. The first digit refers to the sheet number
(printed on the bottom right hand corner of the CAD diagram) and the last two characters refer to
the location on that sheet of the continuation of the circuit (e.g. 1-D4).
If more than one line is represented (indicated by a double thickness line), a dot with a reference
label will follow the route each individual line represents.
