6 Installation
The following section gives a brief description of the basic rack mounting and wiring
procedures.
The following topics are covered in this section.
Section Title Page
6.1 Rack Mounting 6.3
6.2 Rack Wiring 6.5
6.3 Power Supply 6.5
Figure Title Page
6.1 Guide Rails 6.3
6.2 Chassis Connectors 6.3
6.3 Latched Position 6.4
6.4 D-Range Wiring - Rear View 6.5
