HOLE
Defineamountinghole.
RATSNEST
Calculate the shortest airwires and the real mode (filled) display of
polygons. The polygon calculation can be deactivated with the SET
command (Options/Set/Misc). This command will be executed auto
-
maticallyfortheselectedsignalwhiledrawingawirewithROUTE.
AUTO
StartAutorouter.
ERC
Performconsistencycheckofschematicandboard.
DRC
DefineDesignRulesandperformDesign RuleCheck.
ERRORS
ShowerrorsfoundbytheDRCandclearerrorpolygons.
4.4 The LibraryEditorWindow
The Library Editor window opens when you load a library for creating
or editing components. A library normally has three different elements:
packages,symbolsanddevices.
•
Apackageisadevice’shousing,aswillbeusedintheLayoutEdi
-
tor(ontheboard).
•
Thesymbolcontainsthewayinwhichthedevicewillbeshownin
theschematic.
•
Thedevicerepresentsthelinkbetweenone(ormore)symbol(s)
andapackage.Herewedefinetheconnectionbetweenapinofa
symbolandthereferringpadofthepackage.
WecallitaDevicesetifthecomponentexistsinmorethanone
packageand/ortechnologyvariant.
Even if you do not have the schematic module, you can still create and
editsymbolsanddevices.
A library need not contain only real components. Ground or supply
symbols as well as drawing frames can also be stored as devices in a li
-
brary. These symbols do not normally contain any pins. There are also
librariesthatonlycontainpackages.
Extensive examples of the definition of library elements are to be found
in a section entitled Component Design Explained through Examples,
startingonpage 157 inthismanual.
