- A
CHANGE
Change the attributes of an object, e.g. the width of a track or the size
of a text. If the Esc key is pressed after changing a property, the previ
-
ously used value menu will appear. In this way a new value can be con
-
venientlychosen.Seethehelppages.
CUT
Transfer the objects of a previously defined group into the paste buffer.
SeePASTEcommand.NotidenticaltotheWindowscutfunction.
PASTE
Insert objects from the paste buffer into the drawing. Restrictions: see
help.NotidenticaltotheWindowspastefunction.
DELETE
Deletevisibleobjects.
If a group has been defined, it can be deleted with the right
mouse
button.
DELETE SIGNALS erases all signals in the layout, provided there is no
consistentschematicopened.
The DELETE command deletes an entire polygon when clicking on a
polygonwirewiththe Shift keypressed.
Keeping the Ctrl key pressed while clicking on a wire bend will delete
the bend. A new direct connection between the next bends will be
drawnnow.
If objects cannot be deleted, the reason can lie with error polygons re
-
lated to the DRC command. They can be deleted with the ERRORS
command (ERRORS CLEAR). If layer 23, tOrigins, or 24, bOrigins,is
notdisplayed,componentscannotbedeleted.
ADD
Add library parts to a drawing. It offers a convenient search function.
TheUSEcommanddetermineswhichlibrariesareavailable.
PINSWAP
Swap two signals connected to equivalent pads of a component, pro
-
videdthepinshavebeendefinedwiththesameswaplevel.
REPLACE
Replace a package with another package from any library. This is
permitted as long as you are working in a layout that is not connected to
a consistent schematic by Forward&Back Annotation. In that case you
must use CHANGE PACKAGE in order to change the package variant.
48
