- A
selection/deselectionofalllibraries(ofthefolder).
This command has to be used in script files in order to choose the li
-
braryyouwanttotakepartsfrom.
SCRIPT command: Execute a script file. This enables you to execute
anycommandsequencewithafewmouseclicks.
RUNcommand: StartaUserLanguageprogram(ULP).
WINDOW command: These icons represent different modes of the
WINDOW command: Fit drawing into the screen (Alt-F2), zoom in
(F3),zoomout(F4),redrawscreen(F2),displaynewarea.
That part of the drawing displayed on the screen can be shifted by hold
-
ingdownthe Ctrl keyandmovingthemouseatthesametime.
To move the current drawing window click the middle mouse button
andmoveyourmouse!
Press the Shift key simultaneously and you are allowed to scroll be
-
yonedthedrawingboundaries!
UNDO and REDO: These commands allow you to cancel previous
commands and to execute commands which have previously been can
-
celled. Functionkeys:F9andF10(default).
TerminatestheexecutionofEAGLEcommands(Edit/Stopcommand).
Starts the execution of the active EAGLE command. This is only neces
-
saryiffurtherparameterscouldbeenteredbytheuser.
TheSchematicCommandToolbar
INFO
Providesinformationabouttheobjecttobeselected.
SHOW
Highlightstheobjecttobeselected.
DISPLAY
Select and deselect the layers to be displayed. See the Appendix for the
meaningofthelayers.Forfurtherdetailspleaseseehelpfunction.
38
EAGLEManual
