9.8 GerberFilesfor Photoplotterswith Fixed
Aperture Wheels
This section goes into more detail on the definition of the aperture
table. Some circuit board manufacturers may perhaps still be using a
Gerber plotter that works with a fixed aperture wheel. In such a case it is
necessary to adapt the aperture table to the restricted facilities of the
Gerber plotter. Files for Gerber photoplotters with fixed aperture
wheels are generated with the GERBER driver. It is essential to confer
with your photoplot service bureau in good time, so as to adjust
EAGLEtotheavailableapertures.
There are various types of apertures. They differ in size and shape. The
most common are circle, octagon, square, thermal and annulus symbols.
Thedrawingapertureusedfortracksisnormallytheroundaperture.
You must specify the aperture configuration before you can generate
filesforafixedaperturewheelphotoplotter.
To do this, enter the configuration file for apertures name.whl e.g. with
the EAGLE text editor, and then load this file into the CAM Processor
by clicking the Wheel button after selecting the GERBER device driver
(seealsothe SetOutputParameters section,page 220).
The CAM Processor normally chooses the aperture from the configura-
tion file appropriately for each object. For each line, a draw aperture
must be present with the appropriate diameter. For each symbol (e.g.
pad) an aperture with the correct shape and size is required. If this is not
available,nooutputfilewillbeproduced.
InfoFile
The apertures which have not been found are then listed in the file
name.gpi, where name here stands for the name chosen for the output
file.
You can then change your board in such a way that the existing aper
-
tures can be used. After generating plot or drill files you should always
checktherelatedinfofiles.
ApertureEmulation
If objects exist in a drawing which are not compatible with the available
aperture sizes, it is possible to emulate the desired dimensions by select
-
ing the Emulate Apertures option. The CAM Processor then selects
smaller apertures to emulate dimensions which are not matched by aper
-
ture sizes. Emulation results in longer plot times and higher costs, so it
shouldbeavoidedwheneverpossible.
225
PreparingtheManufacturingData
