RotatingaPackageasaWhole
To come back to the example of this chapter, please open the library
my_lib.lbr andeditthepackage LCC-20.
Display all layers with DISPLAY ALL to make sure you have all objects
rotated.NowuseGROUPanddrawaframearoundeverything.
Usethe ROTATEcommandtorotatethe group:
Now click with the left mouse into the Angle box of the paramter tool
-
bar and type in the requested angle. Then use a right mouse click into
thegrouptodefinetherotationpoint.
Thepackageisshownnowinthegivenangle.
Alternativelyyoucanworkwiththecommandline:
ROTATER22.5(>00)
rotates, for example, the previously selected group 22.5° further around
the point (0 0). The > sign (right angle bracket) within the parenthesis
for coordinates causes the rotation of the whole group (as a right mouse
clickonthepoint(00)woulddo).
PackageswithRadialPadArrangement
It is possible to work with polar coordinates to place pads or SMDs in a
radial arrangement. Set a suitable reference point, for example, in the
center of the package with the MARK command first. The command
lineshowsnowadditionalinformationaboutthecursorposition.
PackageEditor: RelativeandPolarCoordinatesDisplay
Values marked with an R are relative values referring to the previously
set reference point. The leading P indicates polar values referring to the
referencepoint.
Example:
Three pads are to be placed on the circumference of a circle with a radius
of50mm.Thecenterofthepartisatposition(00).
GRIDMM;
MARK(00);
PAD'1'(P500);
PAD'2'(P50120);
PAD'3'(P50240);
Depending on the used pad shape it may be useful to place the pads ro
-
tated(forexamplefor Long padsorSMDs).
It is possible to enter the angle directly in the parameter toolbar or in
thecommandlinewhilethePADorSMDcommandisactive.
