SMDcommand:Parametertoolbar
All properties can be altered after placement using the CHANGE com
-
mandorbytypingthecommanddirectlyonthecommandline.
Select To p as the layer, even if the component will later be placed on the
underside of the board. SMD components are located on the other side
of a board using the MIRROR command. This moves the elements in all
the t..-layersintothecorresponding b..-layers.
Place the two SMD pads (which in EAGLE are just called SMDs) at the
desired distance. It may be necessary first of all to alter the grid setting
to a suitable value. The SMD can be rotated with the right mouse button
beforeitisplaced.
The parameter ROUNDNESS specifies whether the corners of the
SMDs are to be rounded. By default this value is set to 0% (no round
-
ing). This value is usually kept, since the final roundness of SMDs is
specified in the Design Rules. The help system provides you with more
informationaboutthisparameter.
Angle determinestherotationoftheSMDpad.
The INFO command provides you here with a quick summary of the cur
-
rentpropertiesofaSMDorpad.
PadName
You can now enter the names, such as 1 and 2, for the pads or SMDs us
-
ingtheNAMEcommand.
Silkscreenand DocumentationPrint
Now use the WIRE command to draw the silkscreen symbol in layer 21,
tPlace. This layer contains what will be printed on the board. It is up to
you how much detail you give to the symbol. Set a finer grid size if it
helps.
Take the information provided in library.txt as a guideline for the design
of components.. The line thickness for the silk screen is usually 0.01
inch(0.254mm).
You can also use the ARC, CIRCLE, RECT and POLYGON com
-
mandstodrawthesymbolsforthesilkscreen.
Layer 51, tDocu, is not used to print onto the board itself, but is a sup
-
plement to the graphical presentation which might be used for printed
documentation. Care must be taken in layer 21, tPlace, not to cover any
areas that are to be soldered. A more realistic appearance can be given,
159
ComponentDesignExplainedthroughExamples
