Specification

Say goodbye to chilly mornings with our popular
Com-Pak Bath heater. Set the built-in auto-timer to override
the thermostat so you can warm your bathroom instantly.
ARCHITECTURAL - ENGINEERING INFORMATION
Fan forced up flow electric air heaters are UL listed, factory rated at
120V/240V or dual field rated from 208V to 240V. The powder coated
wall mounting can is made from 20-gauge sheet metal with six electrical
knockouts and a 22 cubic inch wiring compartment. Each heating unit is
of unitized construction and attach to the wall can with a single screw and
is self contained and completely separate from the wall mounting can.
Elements are tube and plate, painted, with an over-sized 16 amp rating
at 240V high temperature manual reset limit switch. A centrifugal blower
is driven by an impedance protected motor. The motor is totally isolated
from the heating element. Metal grill is of one piece, 20-gauge construc-
tion, and finished with a powder coat paint system. All heaters include
a built-in single pole thermostat and 60-minute timer. The Com-Pak Bath
Heater is not to be used with a wall thermostat. The multi-volt option
must be configured for the correct voltage before installing the heater.
The multi-watt option must be configured for the desired wattage
before installing the heater.
TECHNICAL INFORMATION
UL safety standards require the heater to be placed a minimum distance
of 6 inches (15.2 cm) from adjacent surfaces and 4-1/2 inches (11.4 cm) from
the floor. Cadet recommends a 12-inch clearance from all surfaces for
longer and cleaner performance. A 3 foot (91.44 cm) minimum clearance
is required for furniture or other objects placed directly in front of heater.
Install vertically. This heater is not approved for horizontal or ceiling
installation. Electric wall heaters work best when installed on an inside wall.
We recommend installing heater assembly after walls are finished. Heater
must be cleaned every six months minimum.
Com-Pak Bath
Warmth for every morning
cadetheat.com
855.CADET.US
Vancouver, Washington
USA
m
a
d
e
i
n
t
h
e
• Quick, efficient warmth
for the bathroom
• Built-in thermostat and
60-minute auto-timer
• Painted heating element
prevents rust in damp
bathroom environments
• Low-profile grill blends with
any décor
• Includes high-temperature
safety shutoff feature
• Multi-volt and multi-watt options
available to match your room size
• Fits same wall can as our popular
Com-Pak series, for easy install
or replacement of your existing
Com-Pak heater
